Specifically designed for onboard surveillance, this easy-to-install camera delivers a complete 180° or 360° overview regardless of light conditions. Built-in cybersecurity features help prevent unauthorized access and safeguard your system.
Optimized for the transportation industry
Specifically designed for onboard surveillance, AXIS M3057-PLR Mk II complies with transportation industry standards including EN50155 and EN45545-2. Including an M12 connector, it can withstand vibrations ideal for installation in trains and buses. This ruggedized IK10, IP66/67-rated camera can withstand harsh environments. Plus, an active tampering alarm lets you know if your camera has been tampered with. Furthermore, Axis Zipstream with support for H.264 and H.265 video compression significantly reduces bandwidth and storage requirements.
See everything 24/7
This 6 MP panoramic camera offers 360° wide area coverage with just one camera. Ideal for onboard surveillance, you can use one video stream to produce any dewarped views you'd like. It’s possible to stream panorama, quad, corner, and corridor views directly from the camera. And you can digitally pan, tilt, and zoom in on areas of interest in up to four areas simultaneously. Including Axis Lightfinder, it ensures sharp color images in low light. Plus, Forensic WDR delivers clarity even when there’s both dark and light areas in the scene. Furthermore, thanks to Axis OptimizedIR it enables surveillance in total darkness.
Built-in cybersecurity features
AXIS M3057-PLR Mk II comes with built-in cybersecurity functionality to prevent unauthorized access and safeguard your system. Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis devices on your network. Additionally, signed firmware and secure boot guarantee that the firmware hasn’t been compromised and ensure only authorized firmware is installed. And if needed, secure boot guarantees the camera is completely free of malware after a factory default.
| Camera | |||
| Image sensor | CMOS | Image sensor size | 1/1.8" |
| Lightfinder | Lightfinder | Wide dynamic range | Forensic WDR |
| Min illumination / light sensitivity (Color) | 0.16 lux | Min illumination / light sensitivity (B/W) | 0 lux |
| Video | |||
| Max video resolution | 2016x2016 | Max frames per second | 50/60 |
| Day and Night functionality | Yes | Electronic image stabilization | – |
| Lens | |||
| Focal length | 1.56 mm | Horizontal field of view | 183° |
| Vertical field of view | 183° | Compression | Zipstream, H.264, H.265 |
| Compression | |||
| Zipstream | Yes | H.264 | Baseline, High, Main |
| H.265 | Yes | Audio Support | Yes |
| Security | |||
| Signed OS | Yes | Secure boot | Yes |
| General | |||
| Remote focus | – | Remote zoom | – |
| Built-in IR | Yes | OptimizedIR | Yes |
| Local storage | Memory card slot | Operating temperature | -40 to 55°C |
| Outdoor Ready | Yes | Vandal rating | IK10 |
| IP rating | IP66 | Sustainability | PVC free |
| Description | Downloads |
|---|---|
| Datasheet | Download |
