This indoor ligature-resistant (anti-ligature) corner camera delivers 360° panoramic view with no blind spots. Compact and vandal-resistant, it’s easy to clean and install.
Great video performance
AXIS P9117-PV is a 6 MP corner camera that delivers full coverage with no blind spots. It includes Axis Lightfinder 2.0 to capture images with more realistic and saturated colors and sharper images of moving objects. And, with Axis Forensic WDR you’re sure to capture high-quality images even when there’s both dark and light areas in the scene.
Extended possibilities
Built on an Axis system-on-chip, AXIS P9117-PV features Axis edge vault, a hardware-based cybersecurity platform that safeguards the device and protects sensitive information from unauthorized access. With this AI-powered camera, you can run advanced analytics on the edge. For instance, it comes with AXIS Object Analytics preinstalled to detect and classify different objects of interest. With a built-in microphone, it’s out-of-the-box-ready for AXIS Audio Analytics. In addition, elevator door state detector will display if the elevator door is open unexpectedly which could indicate a safety or service issue.
Easy to install and maintain
AXIS P9117-PV is easy to install, thanks to innovative screw gaskets that hold the screws in place during mounting. With a vandal-resistant, IK10-rated casing, it’s ideal for installation in areas prone to vandalism, such as elevators and stairwells. AXIS TP9801 Cover Steel is also available as an accessory. Furthermore, with an abrasion-and chemical-resistant front cover that’s easy to remove, the window can also be cleaned more thoroughly with detergent or graffiti remover.
| Image sensor | CMOS | Image sensor size | 1/1.8" |
| Lightfinder | Lightfinder | Wide dynamic range | Forensic WDR |
| Min illumination / light sensitivity (Color) | 0.17 lux | Min illumination / light sensitivity (B/W) | 0.04 lux |
| Max video resolution | 2160x2160 | Max frames per second | 50/60 |
| Day and Night functionality | Yes | Electronic image stabilization | – |
| Focal length | 1.1 mm | Horizontal field of view | 176 ° |
| Vertical field of view | 176 ° | Remote PTRZ | – |
| Zipstream | Yes | H.264 | Baseline, High, Main |
| H.265 | Yes | AV1 | – |
| Audio Support | Yes | Built-in microphone | Yes |
| PoE Class | 3 | Signed OS | Yes |
| Secure boot | Yes | Secure keystore | Secure Element (CC EAL6+) |
| Axis Edge Vault | Yes | Remote focus | – |
| Remote zoom | – | Built-in IR | – |
| Local storage (memory card slot) | Yes | Operating temperature | -15 to 50 °C |
| Outdoor Ready | – | Vandal rating | IK10 |
| IP rating | IP66 | Designed for repaint | Yes |
| Sustainability | BFR/CFR free, PVC free |
| Description | Downloads |
|---|---|
| Datasheet | Download |
