This all-in-one, outdoor-ready camera delivers superior image quality in 41 MP with exceptional light sensitivity. It’s available with a wide lens for open areas or a tele lens for surveillance from a distance.
See all the details
Built on a dual Axis system-on-chip, this device delivers extreme detail over great distances and excellent forensic value. It offers 41 MP at 15 fps or 8K at up to 30 fps. And a 4/3” image sensor ensures exceptional low-light performance. With a custom-made, tele Canon lens, it’s perfect for long-distance surveillance and delivers extremely high pixel density. Electronic image stabilization (EIS) ensures smooth video in situations where a camera is subject to vibrations, for instance, at sports arenas or windy harbors. Furthermore, Axis Zipstream reduces bandwidth and storage requirements without compromising image quality.
Great coverage in wide, open areas
With a wide (12 – 24 mm) Canon lens and 90°-44° horizontal field of view, AXIS Q1809-LE is perfect for surveillance in wide, open areas. It offers 2x zoom and outstanding light sensitivity to ensure excellent forensic details. Plus, white light IR LEDS (850 nm) let you switch to white light to deter unwanted activity.
Excellent details at great distances
With a tele (50 – 150 mm) Canon lens and 21°-7° horizontal field of view, AXIS Q1809-LE is perfect for great details at long distances. It offers an additional 3x zoom—ideal for identification purposes. Plus, Optimized IR allows for surveillance in complete darkness up to 100 m (328 ft) without the need for extra lighting.

All-in-one and ready for everything
This powerful camera offers everything you need and is out-of-the-box ready to use. Enclosed in a robust aluminum casing, it also includes a mounting arm for easy installation. And a spacious back box ensures secure cable management. It features a custom-made, tele (50 – 150 mm) Canon lens and 21°-7° horizontal field of view. With 3x zoom, it’s ideal for identification purposes. In addition, thanks to PoE out, you can connect and power another device without any additional cabling. This eliminates the need to rent extra ports and simplifies installation.

Secure and robust surveillance
AXIS Q1809-LE includes Axis Edge Vault, a hardware-based cybersecurity platform that safeguards the device and protects sensitive information from unauthorized access. And it offers FIPS 140-3 Level 3 certified secure cryptographic key storage and operations. This robust, weather-protected, outdoor-ready camera is IP66-, IP67-, IK10- and NEMA 4X-rated and features a IK08-rated impact-resistant glass front window. It has an operating temperature range from -40 °C to 55 °C (-40 °F to 131 °F). Furthermore, surge protection minimizes damage in the case of a power surge.
| Image sensor | CMOS | Image sensor size | 4/3" |
| Lightfinder | Lightfinder | Wide dynamic range | - |
| Min illumination / light sensitivity (Color) * | 0.12 / 0.2 lux | Min illumination / light sensitivity (B/W) * | 0.02 / 0.04 lux |
| Max video resolution | 7424x5568 | Max frames per second | 30 |
| Electronic image stabilization | Yes | Focal length * | 12 - 24 / 50 - 150 mm |
| Optical zoom * | 2 / 3 | Horizontal field of view * | 90 - 44 / 21 - 7 ° |
| Vertical field of view * | 49 - 25 / 12 - 4 ° | Zipstream | Yes |
| H.264 | Baseline, High, Main | H.265 | Yes |
| Audio Support | Yes | PoE Class | 6 |
| Signed OS | Yes | Secure boot | Yes |
| Secure keystore | Secure Element (CC EAL6+, FIPS 140-3 Level 3) | Remote focus | Yes |
| Remote zoom | Yes | Built-in IR | Yes |
| Local storage (memory card slot) | Yes | Operating temperature | -40 to 55 °C |
| Outdoor Ready | Yes | Vandal rating | IK10 body, IK08 glass |
| IP rating | IP66, IP67 | Designed for repaint | Yes |
| Sustainability | - | Power (max) | 35.0 W |
| Power (average) | 17.6 W |
| Description | Downloads |
|---|---|
| Datasheet | Download |
