Qt® Emitters are the backbone of the Cambridge Qt X sound masking system.
Qt Emitters are wide dispersion (nearly 180 degrees) direct field loudspeakers with 1.25 inch (3.17cm) drivers and are smaller than a coffee mug. Emitters have DIP switches that allow their volume to be reduced 9 dB in 3 dB decrements. Emitters deliver four uncorrelated audio channels, automatically eliminating phasing. Emitters are plenum-rated, ETL listed, and comply with UL 2043.
Each Emitter comes standard with a slip-ring mount for acoustical tile mounting. These features, along with plug and play installation and easy configuration capability, make Qt X systems the most intelligently engineered and most effective sound masking systems on the market today.
Features
Wide dispersion direct field speakers with 1.25 inch (3.17cm) drivers
Small driver size results in nearly 180-degree dispersion of direct field sound masking
Reduces acoustical interference by using four uncorrelated channels
DIP switches attenuate the volume level up to 9 dB in 3 dB decrements for easy micro-zoning
Plug and play installation and easy configuration
Comes standard with slip ring for acoustical tile mounting
CE marked, ETL listed, and RoHS compliant
Evaluated to the requirements of UL 2043 and is suitable for use in air handling spaces
Met Works with WELL licensing criteria for sound masking
5-year warranty
Not available in the U.S. and Canada
| Emitter Type | Passive with transformer | Frequency Response | Sound Masking: 200Hz–6.3kHz Music/Paging: 200Hz–10kHz |
| SPL (1m) | Min Masking: 30dBA Max Masking: 57dBA Max Music/Paging: 56dBA |
Nominal Impedance | 3.6 kΩ |
| Nominal Dispersion | 170° conical / half space | Channel Selection | 4 auto-sequencing & repeating channels |
| Selectable Attenuation | 0 dB, -3 dB, -6 dB, -9 dB | I/O Connectors | 2 × RJ-45 connectors |
| Cabling | Category UTP, 8 conductor | Max Power Consumption | 0.02 W |
| Driver Diameter | 1.25” (32 mm) | Enclosure | Sealed |
| Color | Black | Overall Diameter | 3.25 in. (83 mm) |
| Depth | 2.5 in. (64 mm) | Weight | 5.6 oz. (159 g) |
| Cutout Diameter | 2.68 in. (68 mm) | Accessories | Ceiling tile mounting ring UTP cable (16ft/30ft) |
| Compliance | ETL (USA/Canada), CE (Europe), RoHS (Europe), UL 1480a & UL 2043 (air handling spaces) | ||
| Description | Downloads |
|---|---|
| BIAMP Cambridge E-A-B-4 4-Pack Black Standard Emitters | 911.0892.900 DataSheet | Download |
