BIAMP CM30DTD 2-Way Ceiling Speaker | 911.0632.900
SKU: 911.0632.900
£287.95 (Excl. VAT)
- Description
- Specifications
- Downloads
-
Biamp CM30DTD 2-Way Ceiling Speaker | 4.25" Woofer, 50W, 70/100V, Zoom Certified
Key Features
Zoom Rooms Certified
Requires only 5.2-inch (131 mm) mounting depth
High speech intelligibility coupled with full-range music reproduction
Thin-edge, magnetically attached grille
Tap switch allows for 70V/100V or 16Ω low impedance operation
Tuned bass reflex port for optimized low frequency performance
Loudspeaker overload protection for 24/7 failsafe operation
Suitable for use in air handling spaces per NFPA 70, NFPA 90
Conforms with City of Chicago codes
ETL listed to conform with UL Std 1480A and UL 2043; Certified to CSA C22.2#62368-1
5-year warranty
The Desono CM30DTD two-way 4.25-inch ceiling loudspeaker delivers crystal clear audio for all your public address and background music needs. Its 4.25-inch polypropylene woofer and 1-inch tweeter results in a high SPL and extremely low distortion, ensuring exceptional clarity over the entire frequency spectrum.
The CM30DTD utilizes a 5-position switchable transformer ranging from 1.75W to 30W with low-impedance bypass for constant-voltage operation, making it an excellent choice for large areas of BGM.
Designed with the installer in mind, they can be blind-mounted from below the ceiling, and feature a magnetic grille for easy toolless installation and removal that can also be painted to match the room decor. Additionally, the tap switch is located on the face of the loudspeaker, so adjustments can be made without requiring ceiling access.
Certified for use with Zoom software. -
Specification Description Diameter 8.8 inches (223 mm) Cutout Diameter 7.6 inches (193 mm) Weight 5.5 lbs (2.5 kg) Mounting 2 mounting clamps with 0.2" - 2.6" range Included Accessories Tile rails, tile rail spacers, cutout template Optional Accessories SQGR square grille Operating Environment Indoor Continuous Power Handling 28V 50W @ 16Ω (200W peak) Loudspeaker Protection 3-step self-resetting Transducers LF: 1 x 4.25" paper cone, HF: 1 x 1" soft dome Operating Mode Passive Operating Range 90 Hz to 22 kHz Nominal Beamwidth 120° conical Transformer Taps - 70V 30W, 15W, 7.5W, 3.75W, 1.75W Transformer Taps - 100V 30W, 15W, 7.5W, 3.75W Nominal Sensitivity @ 1m @ 1W 87 dB, @ 2.83V 83 dB Input Connection (1) 4-way Euroblock connector Nominal Maximum SPL @ 1m Peak 110 dB, Continuous 104 dB Zoom Certification Zoom Certified Certifications ETL, UL 1480A, UL 2043, CSA C22.2#62368-1, NFPA 70, NFPA 90 Safety Features 2 hang points -
Description Downloads BIAMP CM30DTD 2-Way Ceiling Speaker | 911.0632.900 DataSheet Downloads BIAMP CM30DTD 2-Way Ceiling Speaker | 911.0632.900 Drawing Downloads
