BluStream 4x4 Advanced Video Wall Processor | MX44AVW
Our MX44AVW is an advanced 4K HDMI 2.0 multi-purpose high-speed video processing system. The MX44AVW can be configured for 3 different output modes:
- 4x4 seamless matrix switcher
- Advanced video wall solution
- Quad multi-view presentation systemThe MX44AVW supports advanced video wall configurations, allowing individual overlap and rotation of panels; multiview with pre-defined and customisable layouts using PIP, POP, PBP, and up to 4 window layouts.
The MX44AVW features a web browser interface module for control and configuration of the matrix with additional third party control achievable via the front-panel push buttons, IR remote control, RS-232 interface and TCP/IP. The MX44AVW is designed to achieve artistic video wall configurations within retail and showcase style installations.
Key Features
Advanced 4K HDMI 2.0 multi-purpose high-speed video processor supporting matrix, multiview, and video wall functionAdvanced video wall configuration allowing individual overlap and rotation of panels
Multiview mode supports PIP, PBP, POP, Dual, Triple and Quad-windows layouts with pre-defined and customisable configurations
Seamless video switching
Supports HDMI 2.0 4K UHD 60Hz 4:4:4 18Gbps specification including HDR
Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
Supports all known HDMI audio formats including Dolby Atmos, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio transmission
HDMI audio breakout to analogue L/R audio and optical digital outputs concurrently
IR routing
Control via front panel, IR, RS-232, TCP/IP and web-GUI
Supplied with Blustream 5V IR receiver and remote control
HDCP2.2 compliant with advanced EDID management
Box Contents
1 x MX44AVW
1 x Remote control
1 x IR Control Cable - 3.5mm-3.5mm Cable
1 x 19" Rack Mounting kit
4 x Mounting feet
1 x Quick Reference Card
1 x IEC Power Cable -
Feature Description Video Input Connectors 4 x HDMI Type A, 19-pin, female Video Output Connectors 4 x HDMI Type A, 19-pin Audio Input Connectors 5-Pin Phoenix connector (2ch balanced/un-balanced analogue audio) Audio Output Connectors 1 x Optical (S/PDIF), 5-Pin Phoenix connector (2ch balanced/un-balanced analogue audio) Control Ports 1 x DB-9, female Console Control Ports 1 x USB Type C, female TCP/IP Control 1 x RJ45, female IR Input Ports 5 x 3.5mm stereo jack IR Output Ports 4 x 3.5mm mono jack Firmware Upgrade 1 x USB Type A female Rack-Mountable 1U rack height, rack ears included Casing Dimensions (W x D x H) 440mm x 240mm x 44mm Dimensions Including Connections (W x D x H) 440mm x 245mm x 44mm Shipping Weight xxkg TBC Operating Temperature 32°F to 104°F (0°C to 40°C) Storage Temperature -4°F to 140°F (-20°C to 60°C) Power Supply Internal 100-240V AC -
Description Downloads Datasheet Downloads
