BluStream 4x4 HDBaseT™ ARC Matrix Supporting Uncompressed 4K 60Hz 4:4:4

The HMX44-18G Matrix is an industry leading uncompressed, unconverted HDMI 2.0 4K 60Hz 4:4:4 HDCP 2.3/2.2 solution utilising HDBaseT™ 3 technology to deliver HDMI, Bidirectional IR & RS-232, ARC, 1Gb Ethernet, and PoC up to lengths of 100m over a single CAT6A cable.
The HMX44-18G supports uncompressed distribution of the latest HDR resolutions including HDR10/10+ and Dolby Vision resulting in the ultimate in picture quality for your critical viewing areas.
The Matrix also provides advanced features including simultaneous HDBaseT™/HDMI on output 1, video smart scaling on HDBaseT outputs, and an independent 14x4 audio matrix, and ARC. The HMX44-18G includes an in-built web browser interface module for control and configuration of the Matrix, and RS-232, IR and 1Gb Ethernet pass through to enable seamless 3rd party control integration.


Key Features
 Advanced uncompressed, unconverted, HDMI over HDBaseT™ technology offering distribution of bit-for-bit 4K HDMI video and audio over a single CAT6A cable
 Features 4 x HDMI inputs which can be independently routed to 4 x HDBaseT™ outputs
 Output 1 features a simultaneous HDMI and HDBaseT™ output
 Supports distribution of uncompressed HDMI2.0 18Gbps specification including 4K 60Hz 4:4:4 UHD video up to 100m*
 Supports distribution of the latest HDR resolutions including HDR10/10+ and Dolby Vision
 14x4 Audio Matrix independently controllable from video. Audio source inputs include:
 4 x audio breakout from HDMI source inputs
 4 x audio breakout from zone outputs
 4 x audio return from zone outputs*
 1 x optical and 1x analogue audio input
 Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
 Integrated Ethernet switch (LAN Serving) when used with Blustream RX18G receiver (1Gb maximum)
 Web interface module for control and configuration of the Matrix
 Supports bi-directional IR and RS-232 on all HDBaseT™ outputs
 Control via front panel, IR, iOS / Android App, RS-232 and TCP/IP
 Supports PoC (Power over Cable) to power the supplied HDBaseT™ receivers
 Advanced EDID management and HDCP 2.3 compliant
 Supplied with 4 x RX18G HDBaseT™ Receivers

Box Contents
1 x HMX44-18G
4 x RX18G
1 x Rack mounting kit
1 x Remote control
4 x IR emitters
5 x IR receivers
1 x Serial Cable - DB9 to 3-pin phoenix connector
1 x IR Control Cable - 3.5mm-3.5mm Cable
IEC Power Cable(s)
1 x Quick Reference Guide
