The DA11XLR is a multi-input XLR to Dante® networked audio system. The DA11XLR converts 2 input channels of balanced / unbalanced / MIC audio with switchable 48V Phantom power to Dante® digital audio.
The DA11XLR is a plug & play device that is powered using PoE (Power over Ethernet), or via 12V power supply, offers support for AES67 RTP audio transport.
Key Features
• Dante® network interface for 2 x XLR audio inputs
• Converts 2 x balanced / unbalanced / MIC audio sources to Dante® audio channels
• Switchable 48V Phantom power for each MIC XLR input
• Adjustable MIC / line sensitivity from +24dBu to -28dBV for each XLR input
• Supports: 44.1, 48, 88.2 & 96 KHz sample rates @ 16, 24 & 32 Bit
• Configurable Dante® device latency (supports 2, 3, 4, 5 or 10ms configurable using Dante® Controller)
• Supports AES67 RTP audio transport
• Features Class 0 802.3af PoE for powering of product from any PoE switch
• Local 12V power supply input for when network switch does not support PoE*
* PS121PH power supply sold separately
Box Contents
1 x DA11XLR
1 x Quick Reference Guide
| Feature | Specification |
|---|---|
| Casing Dimensions | 120mm x 84mm x 40mm |
| Shipping Weight | 0.3 kg |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature | -4°F to 140°F (-20°C to 60°C) |
| Power Supply | Class 0 IEEE 802.3af PoE PD or 12V/1A DC 2-Pin Phoenix connector |
| Audio Input Connectors | 2 x Analogue Balanced/Unbalanced 3-Pin XLR connector |
| Audio Output Connector | 1 x RJ45, female (100 Mbps Dante® network) |
| Document | Link |
|---|---|
| Datasheet | Downloads |
