Our Contractor CMX88AB 4K HDMI Matrix offers unprecedented performance and value for the custom installation market.
The CMX88AB supports HDMI 2.0 with HDCP 2.2, allowing distribution of 8 HDMI sources to 8 displays. This enables all sources to be viewed as required within a matrix configuration.
The unit transmits all HDMI resolutions up to and including 4K @ 60Hz 4:4:4. The 8-Way matrix also includes audio breakout, EDID management and a web browser interface module for control and configuration of the matrix.
Key Features
Features 8 x HDMI inputs which can be independently routed to 8 x HDMI outputs
Supports HDMI 2.0 18Gbps specification including HDR
Supports up to 4K UHD 60Hz 4:4:4
Independent video down conversion on all HDMI outputs allowing for displays only capable of supporting lower 4K video resolutions (4K @ 60Hz 4:2:0) to receive native 4K @ 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on remaining video outputs
Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
Supports all known digital HDMI audio formats including Dolby TrueHD, Atmos; DTS-HD Master Audio and DTS:X transmissions
HDMI audio breakout to associated output analog L/R audio and coaxial digital outputs concurrently
Web interface module for control and configuration of matrix
Control via front panel, IR, RS-232 and TCP / IP
3rd Party drivers available for major control brands
Advanced EDID management
HDCP 2.2 compliant
Box Contents
1 x CMX88AB
1 x 12V/3A DC Power Supply
1 x Remote Control
1 x IR Receiver
1 x Mounting Kit
1 x Quick Reference Guide
| Feature | Details |
|---|---|
| Video Input | 8x HDMI, locking |
| Video Output | 8x HDMI, locking |
| Audio Output | 8x RCA (S/PDIF), 8x RCA (L/R) |
| TCP/IP Control | 1x RJ45 |
| RS-232 Port | DB-9, female |
| IR Input | 1x 3.5mm stereo jack |
| Mounting Kit | Included |
| Dimensions (WxDxH) | 441 x 226 x 45 mm |
| Dimensions w/ Connectors | 441 x 234 x 50 mm |
| Shipping Weight | 3.5 kg |
| Operating Temp | 32°F to 104°F (0°C to 40°C) |
| Storage Temp | -4°F to 140°F (-20°C to 60°C) |
| Power Supply | 12V/3A DC |
| Description | Downloads |
|---|---|
| BluStream Contractor 8x8 HDMI Matrix | CMX88AB Downloads, Drivers and Firmware | Downloads |
