BluStream HDMI over Coax Extender Set | CEX4K-KIT
Our CEX4K-KIT HDMI extender set offers HDMI distribution over a single Coaxial cable.
The product delivers HDMI & Bi-directional IR up to lengths of 100m @ 4K 60Hz 4:4:4
Key Features
• Extends 4K HDMI signals up to a distances of 100m over a single 75 ohm coaxial cable
• Supports up to 4K 60Hz 4:4:4 UHD video*
• Supports Bi-directional IR from input and output locations
• Supports PCM 2.0 channel audio
• Supplied with Blustream IR receiver and emitter
• Smart EDID management
• HDCP 2.2 compliant
*Note: HDR 10/12 bit formats not supported
Requires local power at both Transmitter and Receiver devices
Box Contents
1 x CEX4K-TX
1 x CEX4K-RX
2 x 5V/1.2A DC power supply
1 x IRE1 emitter
1 x IRR receiver
2 x Mounting brackets
2 x F-type to BNC adaptor
1 x Quick reference guide
-
Feature |
CEX4K-TX |
CEX4K-RX |
Video Input Connectors |
1 x HDMI Type A |
1 x BNC connector |
Video Output Connectors |
1 x BNC connector |
1 x HDMI Type A |
IR Input Ports |
1 x 3.5mm stereo jack |
1 x 3.5mm stereo jack |
IR Output Ports |
1 x 3.5mm mono jack |
1 x 3.5mm mono jack |
Product Upgrade |
1 x Micro USB, female |
1 x Micro USB, female |
Dimensions (Casing - W x D x H) |
72.7mm x 88.8mm x 24mm |
72.7mm x 88.8mm x 24mm |
Dimensions Including Connections (W x D x H) |
72.7mm x 106.8mm x 24mm |
72.7mm x 106.8mm x 24mm |
Supported Video Formats |
Not compatible with 4K HDR |
Not compatible with 4K HDR |
Supported Audio |
PCM 2.0 channel audio |
PCM 2.0 channel audio |
-
