Our NPA20DA networked power amplifier delivers advanced audio integration within a commercial or residential AV installation.
The NPA20DA features a 2 x 10W digital amplifier (1 x 20W mono) audio output and Dante® audio integration.
The NPA20DA can be powered via PoE or PoE+ from a compatible network switch, or locally should the switch not support PoE. The unit also includes the ability to lower the amplifier power output subject to PoE capabilities, DSP with a 31 band EQ, audio delay for lip sync correction, and control via front panel, RS-232, TCP/IP, web-GUI or 12V trigger.
Key Features
• Advanced network audio amplifier with Dante® integration
• Supports 2 x 10W @ 4 / 8 ohm, 1 x 20W @ 4 / 8 ohm
• Supports power via PoE+ on Dante® LAN connection or local power supply*
• 2ch Dante® / AES67 audio input
• DSP with 31 band EQ with +3dB/-10dB and audio delay
• Local 0V / 5~12V input trigger for automated power control
• Control via front panel, RS-232 and IP
• Auto standby mode with signal sensing
| Feature | Specification |
|---|---|
| Audio Inputs | 1 x RJ45 Dante® Audio connection |
| Speaker Outputs | 1 x 4-Pin Phoenix connector (4 / 8 ohm speaker) |
| RS-232 Serial Port | 1 x 3-Pin Phoenix connector |
| Trigger Input | 1 x 2-Pin Phoenix connector |
| Casing Dimensions (WxHxD) | 112mm x 144mm x 22mm |
| Shipping Weight | 1.0kg |
| Operating Temperature | 32°F to 104°F (0°C to +40°C) |
| Storage Temperature | -4°F to 140°F (-20°C to +60°C) |
| Power Supply | PoE+ Type 2 Class 4, or 24V/1.25A DC 4-pin DIN (not included) |
| Description | Downloads |
|---|---|
| Datasheet | Downloads |
| Manual | Downloads |
