BluStream NPA20ARC 2ch HDMI ARC Networked Power Amplifier

BluStream NPA20ARC 2ch HDMI ARC Networked Power Amplifier

SKU: NPA20ARC
Part Number: NPA20ARC
Condition: Brand New
Purchase Orders Accepted
Save £25.00 Save £25.00

£415.00 (Excl. VAT)

- £498.00 (Inc. VAT)
£415.00 - £415.00
- - £498.00
Availability:
16 in stock
payment-icons

Bulk Price & Price Match Request

Contact our expert sales team on 020 8191 9223 for best price and dedicated assistance.

Educational & Public Sector Prices Available

For more details, please call us at 020 8191 9223 or email us at info@screenmoove.com

  • Description
  • Specifications
  • Downloads

  • BluStream NPA20ARC 2ch HDMI ARC Networked Power Amplifier

    Our NPA20ARC networked power amplifier delivers advanced audio integration within a commercial or residential AV installation within smaller zones, or where voice re-enforcement is required.

    The NPA20ARC features a 2 x 10W digital amplifier (1 x 20W mono) audio output with ARC audio integration, allowing simple connection and control from any ARC compatible display (2ch
    audio only).

    The NPA20ARC can be powered via PoE or PoE+ from a compatible network switch, or locally should the switch not support PoE. The unit also includes the ability to lower the amplifier power output subject to PoE capabilities, DSP with a 31 band EQ, audio delay for lip sync correction, daisy chain audio and control feature for linking up to 4x NPA20 devices and control via ARC, front panel, RS-232, TCP/IP, web-GUI or 12V trigger.


    Key Features
    • Advanced network audio amplifier with ARC integration
    • Supports 2 x 10W @ 4 / 8 ohm, 1 x 20W @ 4 / 8 ohm
    • Supports power via PoE+ on LAN connection or local power supply*
    • 2ch ARC audio input
    • Supports 2ch balanced / unbalanced audio in and out with master / slave amp control feature allowing daisy chain of up to 4x NPA20 amplifiers
    • DSP with 31 band EQ with +3dB/-10dB and audio delay
    • Local 0V / 5~12V input trigger for automated power control
    • Control via ARC, front panel, RS-232 and IP
    • Auto standby mode with signal sensing
    • In-built web-GUI for setup and control

    * Amp power limited when using PoE / PoE+

    Box Contents
    1 x NPA20ARC
    1 x Mounting Kit
    1 x Quick Reference Card

  • Feature Specification
    Casing Dimensions 169mm x 144mm x 22mm
    Shipping Weight 1.2kg
    Operating Temperature 32°F to 104°F (0°C to 40°C)
    Storage Temperature -4°F to 140°F (-20°C to 60°C)
    Power Supply PoE+ Type 2 Class 4, or 24v/1.25A DC 4-pin DIN
    Audio Inputs 1 x HDMI Type A 19-pin female ARC, 1 x 5-pin Phoenix connector
    Audio Output Connectors 1 x 5-pin Phoenix connector
    Speaker Outputs 1 x 4-Pin Phoenix connector (4 / 8 ohm)
    RS-232 Serial Port 1 x 3-Pin Phoenix connector
    Trigger Input 1 x 2-Pin Phoenix connector
