Optimized for use with the EX-1280C, EX-12AEC, and EX-440C, the EX-8ML Dante endpoint, is a convenient, cost effective solution for connecting up to 8 conferencing microphones over a single Cat 5/6 cable. Whether used under a conference table, daisy-chained with other EX or endpoints, or standalone in a rack, the EX-8ML adds 8 high-quality microphone/line inputs, 8 GPI, and 16 GPO to your networked audio system. Autodiscovery, drag and drop programming, auto-routing routing, and simplified logic control in ControlSpace Designer make configuring the EX-8ML easy. Tasks such as configuring microphone LED status and microphone mute actions are greatly simplified within ControlSpace Designer without requiring external control system programming.
FEATURES
Applications
Designed for a wide range of applications, including:
Boardrooms
Medium/large conference rooms
Courtrooms
Distance learning
Auditoriums
Multipurpose spaces
| Feature | Description |
|---|---|
| Frequency Response | 20 Hz – 20 kHz (±1 dB) |
| THD+N | < 0.01% at any gain setting, input signal 3 dB below max |
| Input Channels | 8 balanced, mic/line |
| Connectors | (8) 7-pin Euroblock, 3.81 mm, detachable |
| Equivalent Input Noise | -115 dBu at +45 dB gain |
| Sensitivity Options | 0 dB, +15 dB, +30 dB, +45 dB, software-selectable |
| Input Impedance | > 1.8 kΩ at any gain setting |
| Max Input Level | +8 dBu at 0 dB gain |
| Phantom Power | 48 VDC, software-selectable per input |
| Digital Connectors | (1) RJ-45 Dante in / (1) RJ-45 Dante out |
| Compliance | FCC Part 15 Class A; UL 60950-1; CAN/CSA C22.2 No. 60950-1-07; IEC 60950-1:2005 |
| Control Inputs | (8) general-purpose (1 per audio input), 7-pin Euroblock, 3.81 mm |
| Control Outputs | (16) general-purpose (2 per audio input), 7-pin Euroblock, 3.81 mm |
| Electrical Connectors | (1) RJ-45 port / (1) Euroblock, 2 pins |
| Power Range | 12 VDC, daisy-chainable |
| PoE Class | Class 0 802.3at PoE+, PD-compliant |
| DC Power | 12 VDC, 200 mA |
| AC Power Consumption | 5.6 W + 2 W phantom power (if used) |
| Compatible with | ControlSpace EX-1280, EX-440C, EX-1280C, EX-12AEC, EX Endpoint Mic Extension Cable, EX Endpoint Mounting Bracket |
| Software Applications | ControlSpace Designer 5.0 or later (Windows) |
| LED Indicators | (1) power LED, (8) input signal status LEDs |
| Colors | Black |
| Mounting | (2) mounting tabs |
| Operating Temp | 0 °C to 40 °C (32 °F to 104 °F) |
| Dimensions (H×W×D) | 1.1 × 8.4 × 5.2 in (29 × 213 × 132 mm) |
| Product Codes | 772045-0110: ControlSpace EX-8ML |
| Included in Packaging | (1) ControlSpace EX-8ML (1) mounting template (4) mounting screws (1) installation guide (10) cable ties (2) 2-pin Euroblock connectors (8) 7-pin Euroblock connectors |
| Description | Downloads |
|---|---|
| BOSE ControlSpace EX-8ML Microphone/GPIO Dante Endpoint | 772045-0110 DataSheet | Downloads |
| BOSE ControlSpace EX-8ML Microphone/GPIO Dante Endpoint | 772045-0110 Installation Guide | Downloads |
