The CDi DriveCore Series is an evolution in amplification, providing an impressive mix of high-performance; rich feature set, and competitive cost. Using technology derived from our flagship Installed Sound amplifier (Crown DriveCore Install series), the CDi DriveCore 2|1200 offers streamlined functionality to work in almost any large sized installation such as cinema, houses of worship, hotels, cruise lines, and more. Designed for ease-of-use in a variety of applications, the 2|1200 is a 2-channel amp that includes network control/monitoring, high-level DSP, front-panel interface, and support for driving up to 100Vrms speaker loads without requiring a transformer. The entire CDi DriveCore line comes pre-loaded with JBL speaker tunings to help make installations quicker and easier.
| Feature | Description |
|---|---|
| BLU link | No |
| Channels | 2 |
| Sensitivity | 0.7V RMS (for full rated power at 8Ω) |
| Rated Power Output | 1200W per channel @ 4Ω |
| Signal to Noise Ratio | >104 dB (ref. rated power, 100V, 20Hz–20kHz @ 8Ω) |
| THD | 0.35% (full rated power, 20Hz–20kHz) |
| Damping Factor | >1000 (20Hz–100Hz) |
| Frequency Response | ±0.25 dB (8Ω, 20Hz–20kHz) |
| Crosstalk | >80 dB (below rated power, 20Hz–1kHz) |
| Input Impedance | 20 kΩ balanced, 10 kΩ unbalanced |
| Dimensions | 19 x 3.5 x 14.71 in (W x H x D, excl. 1.3 in front protrusion) |
| Weight | 17.2 lbs (7.8 kg) |
| Power Supply Connector | 15A IEC connector, 100–240V |
| Description | Downloads |
|---|---|
| Crown CDi 2|1200 2-Channel 1200W Power Amplifier with DSP & Network Control | NCDI2X12-U-UK DataSheet | Download |
