| Hot Pluggable | Yes | MSA Compliant | Yes |
| RoHS Compliant | Yes | Standard | IEEE802.3z / 1000BASE-LX |
| Transceiver Type | SFP | Fiber Channel Standard | 100-SM-LC-L |
| Fiber Media | Single-Mode | Distance | 10km |
| Speed | 1.25Gbps | Connector | Duplex LC |
| Direction | Single-direction | Wavelength | 1310nm |
| TX Power (Max) | -3dBm | TX Power (Min) | -8dBm |
| RX Power (Max) | -3dBm | RX Power (Min) | -24dBm |
| Sensitivity | -24dBm | Cable Type | Single-mode 9/125um |
| Power | 3.3V | Max Input Current | 300mA |
| Min Power Budget | 16dB | Max Power Budget | 21dB |
| Heat Generated | 2.376 kJ/h | MTBF | 223,857 hours |
| Operating Temp | -40~85℃ | Storage Temp | -40~85℃ |
| Humidity (Operating) | 5%~95% | Humidity (Storage) | 5%~95% |
| Dimensions | 13.7 x 55.4 x 8.5mm | Weight | 20g |
| Bail Latch Colour | Blue | EMI | CE, FCC, VCCI |
| Safety | LVD, EN 60825-1, EN 60825-2 |
| Description | Downloads |
|---|---|
| Datasheet | Download |
