Technology |
3LCD Technology, RGB liquid crystal shutter |
LCD Panel |
0.59 inch with C2 Fine |
Image |
Color Light Output: 3,200 Lumen- 1,900 Lumen (economy) |
|
White Light Output: 3,200 Lumen - 1,900 Lumen (economy) |
Resolution |
1080p |
High Definition |
Full HD |
Aspect Ratio |
16:9 |
Contrast Ratio |
10,000 : 1 |
Light source |
Lamp |
|
Lamp: 214 W, 4,000 h durability, 7,000 h durability (economy mode) |
Keystone Correction |
Auto vertical: ± 30 °, Auto horizontal ± 20 ° |
Colour Video Processing |
10 Bits |
2D Vertical Refresh Rate |
100 Hz - 120 Hz |
Colour Reproduction |
Up to 1.07 billion colours |
Optical |
Throw Ratio: 1.02 - 1.23:1 |
|
Zoom: Manual, Factor: 1 - 1.2 |
|
Screen Size: 30 inches - 300 inches |
|
Projection Distance Wide: 0.7 m - 6.8 m |
|
Projection Distance Tele: 0.8 m - 8.2 m |
|
Projection Distance Wide/Tele: 1.35 m - 1.62 m (60 inch screen) |
|
Projection Lens F Number: 1.58 - 1.7 |
|
Projection Lens Focal Length: 13.52 mm - 16.22 mm |
|
Projection Lens Focus: Motorized |
|
Offset: 10 : 1 |
Connectivity |
USB Display Function: 3 in 1: Image / Mouse / Sound |
|
Interfaces: USB 2.0-A, USB 2.0, VGA in, HDMI in, Composite in, Jack plug in, Miracast, MHL, NFC |
|
Wireless LAN: IEEE 802.11b/g/n, Wireless LAN b/g/g 25GHz |
Advanced Features |
Security: Kensington lock, Wireless LAN security, Password protection |
|
2D Colour Modes: Dynamic, Cinema, Presentation, sRGB, Blackboard, DICOM SIM |
|
Other features: AV Mute Slide, Built-in speaker, Document Camera Compatible, Fit to Screen, Gesture Presenter, Home Screen, Instant on/off, JPEG Viewer, Long |
