Technology |
Projection System |
3LCD Technology, RGB liquid crystal shutter |
|
LCD Panel |
1.43 inch with C2 Fine |
Image |
Color Light Output |
30,000 Lumen - 20,000 Lumen (economy) IDMS15.4 |
|
White Light Output |
30,000 Lumen - 20,000 Lumen (economy) ISO 21118:2012 |
|
Portrait Colour Light Output |
30,000 lm |
|
Portrait White Light Output |
30,000 lm |
|
Resolution |
WUXGA |
|
Resolution Enhancement |
4K enhancement |
|
Aspect Ratio |
16:10 |
|
Contrast Ratio |
Over 2,500,000: 1 |
|
Native Contrast |
3,500: 1 |
Light Source |
Light Source |
Laser |
|
Laser Light Source Durability |
20,000 hours High, 30,000 hours Eco |
Optical Features |
Keystone Correction |
Manual vertical: ±45°, horizontal ±30° |
|
Colour Video Processing |
10 Bits |
|
Colour Reproduction |
Up to 1.07 billion colours |
|
Zoom |
Motorized |
|
Lens |
Optical, varies by lens |
|
Lens Shift |
Motorized - Vertical ±65%, horizontal ±30% |
|
Lens Position Memory |
10 positions |
|
Screen Size |
100 inches - 1,000 inches |
|
Projection Lens Focus |
Motorized, varies by lens |
|
Offset |
Varies by lens |
|
Interchangeable Lens |
Yes |
Connectivity |
Interfaces |
USB, Ethernet, Wireless LAN (optional), VGA, DVI, BNC, HDBaseT, HD-SDI, HDMI |
Advanced Features |
Security |
Security bar, Control panel lock, Password lock, Wireless LAN security |
|
Other Features |
4K enhancement, Absolute Black, Auto Calibration, Frame interpolation |
Video Color Modes |
|
Cinema, Dynamic, Natural, Presentation, DICOM SIM, Multi Projection, BT709 |
Control |
Projector control |
AMX, Crestron, Extron XTP |
General |
Power Consumption |
1,748 Watt (Normal), 1,511 Watt (Eco), 0.5 Watt (Standby) |
|
Heat Dissipation |
7,905 BTU/hour (max) |
|
Supply Voltage |
AC 200 V - 240 V, 50 Hz - 60 Hz |
|
Product Dimensions |
790 x 710 x 299 mm (Width x Depth x Height) |
|
Product Weight |
63.8 kg |
|
Noise Level |
Normal: 49 dB (A) - Economy: 41 dB (A) |
Software Included |
|
EasyMP Monitor, EasyMP Multi PC Projection |
Options |
|
Wireless LAN unit |
Room Type / Application |
|
Large Meeting Room / Auditorium, Projection Mapping, Rental / Staging, Visitor Attraction |
Positioning |
|
Ceiling Mounted, Flying Frame |
Colour |
|
White |
Other |
Warranty |
60 months Carry in or 20,000 hours |
