Projection System |
3LCD Technology, RGB liquid crystal shutter |
LCD Panel |
0.59 inch with C2 Fine |
Image |
|
Color Light Output |
3,000 Lumen - 1,900 Lumen (economy) |
White Light Output |
3,000 Lumen - 1,900 Lumen (economy) |
Resolution |
WXGA |
High Definition |
HD ready |
Aspect Ratio |
16:10 |
Contrast Ratio |
10,000 : 1 |
Light source |
Lamp |
Lamp |
206 W, 4,000 h durability, 7,000 h durability (economy mode) |
Keystone Correction |
Auto vertical: ± 30 °, Manual horizontal ± 30 ° |
Colour Video Processing |
10 Bits |
2D Vertical Refresh Rate |
100 Hz - 120 Hz |
Colour Reproduction |
Up to 1.07 billion colors |
Optical |
|
Throw Ratio |
1.04 - 1.26:1 |
Zoom |
Manual, Factor: 1 - 1.2 |
Screen Size |
30 inches - 300 inches |
Projection Distance Wide |
0.7 m - 6.8 m |
Projection Distance Tele |
0.8 m - 8.2 m |
Projection Distance Wide/Tele |
1.35 m - 1.62 m (60 inch screen) |
Projection Lens F Number |
1.58 - 1.7 |
Projection Lens Focal Length |
13.52 mm - 16.22 mm |
Projection Lens Focus |
Manual |
Offset |
10 : 1 |
Connectivity |
|
USB Display Function |
3 in 1: Image / Mouse / Sound |
Interfaces |
USB 2.0-A, USB 2.0, VGA in, HDMI in, Composite in, Jack plug in, MHL, Wireless LAN IEEE 802.11b/g/n, Wireless LAN b/g/g 25GHz |
Epson iProjection App |
Ad-Hoc / Infrastructure |
Advanced Features |
|
Security |
Kensington lock, Wireless LAN security, Password protection |
Other features |
AV Mute Slide, Built-in speaker, Document Camera Compatible, Home Screen, Instant on/off, JPEG Viewer, Long lamp life, MHL audio/video interface, PC Free, Projection App for Chromebook, Quick Corner, Split-Screen-Function, Wireless LAN capable, iProjection App |
Video Color Modes |
Blackboard, Cinema, Dynamic, Presentation, sRGB, DICOM SIM |
General |
|
Power consumption |
252 Watt - On mode power consumption (Normal) |
|
277 Watt (Peak), 200 Watt (Eco), 0.34 Watt (Energy saving standby) |
Supply Voltage |
AC 100 V - 240 V, 50 Hz - 60 Hz |
Product dimensions |
292 x 213 x 44 mm (Width x Depth x Height) |
Product weight |
1.8 kg |
Noise Level |
Normal: 39 dB (A) - Economy: 30 dB (A) |
Supported Temperature |
Operation 5° C - 40° C, Storage -10° C - 60° C |
Supported Humidity |
Operation 20% - 80%, Storage 10% - 90% |
Included Software |
EasyMP Multi PC Projection |
Options |
|
Air filter, Ceiling mount, Document camera, Setting plate, Spare lamp, WP System - ELPWP20, Wireless transmitter - ELPWT01 |
|
Loudspeaker |
1 Watt |
What's in the box |
Carrying bag, HDMI Cable 1.8m, Power cable, Remote control incl. batteries, Software (CD), USB cable |
Room Type / Application |
Boardroom, Huddle space / Portable, Large Meeting Room / Auditorium |
Positioning |
Ceiling Mounted, Desktop |
Colour |
White / Black |
Other |
Warranty: 60 months Carry in, Lamp: 60 months or 1,000 h |
