Epson V11H923640/EB-805F Digital Signage Solution Projector - 5000 Lumens
Digital signage solution
Ultra-short-throw signage projector Compact, unobtrusive design.
Up to 130-inch display Full HD resolution, 5,000 lumen brightness and 3LCD technology
Fit and forget reliability Low maintenance laser projector with a 5 year warranty
Easy installation 360 degree rotation with portrait projection support
Flexible playback Play content directly from a USB stick
Innovative and cost effective
Epson's advanced laser technology is robust and reliable, providing a fit-and-forget digital signage solution. It offers bright and vivid colours in a cost-effective solution that's capable of large display sizes.
Large and scalable images
The EB-805F enables scalable display sizes of up to 130 inches, in Full HD resolution with 5,000 lumen brightness and 3LCD technology for bright colours and high display quality even in bright spaces.
Versatile and easy to install
This sleek, stylish and bright display solution offers the flexibility to fulfil the most exacting brief, and the versatility to work in tight spaces. It can be mounted on the wall, ceiling, floor, or even hidden away to create added mystery. Its ultra-short-throw design enables projection of large images from a short distance. A white version is also available.
Flexible playback options
Content can be played directly from a USB stick, including: playlists, videos, and signage content using the built-in content playback feature and Epson Projector Content Manager software. Users can benefit from multi-projector and daisy-chain support for built-in edge blending, or illuminate an entire wall with one huge image. Also, the split screen feature allows users to connect multiple input sources to display different content sources simultaneously.
| Technology | |
|---|---|
| Projection System | 3LCD Technology |
| LCD Panel | 0.62 inch with C2 Fine |
| Image | |
| Color Light Output | 5,000 Lumen- 3,500 Lumen (economy) In accordance with IDMS15.4 |
| White Light Output | 5,000 Lumen - 3,500 Lumen (economy) In accordance with ISO 21118:2020 |
| Resolution | 1080p |
| Aspect Ratio | 16:9 |
| Contrast Ratio | Over 2,500,000 : 1 |
| Light source | Laser |
| Laser Light source | 20,000 hours Durability High, 30,000 hours Durability Eco |
| Keystone Correction | Manual vertical: ± 3 °, Manual horizontal ± 3 ° |
| Optical | |
| Throw Ratio | 0.27 - 0.37:1 |
| Zoom | Digital, Factor: 1 - 1.35 |
| Lens | Optical |
| Screen Size | 65 inches - 130 inches |
| Projection Distance Wide | 0.4 m (65 inch screen) |
| Projection Distance Tele | 0.8 m (130 inch screen) |
| Projection Lens F Number | 1.5 |
| Projection Lens Focal Length | 3.9 mm |
| Projection Lens Focus | Manual |
| Offset | 9 : 1 |
| Connectivity | |
| USB Display Function | 2 in 1: Image/ Sound |
| Interfaces | USB 2.0-A (2x), USB 2.0, Powered USB, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac (optional), VGA in (2x), VGA out, HDMI in (3x), HDMI out, Composite in, HDBaseT, Miracast (optional), Jack plug out, Jack plug in (3x) |
| Epson iProjection App | Ad-Hoc / Infrastructure |
| Network Protocol | HTTPS, IPv6, SNMP, ESC/VP.net, PJLink |
| Advanced Features | |
| Security | Kensington lock, Password lock, Padlock, Security cable hole, Password protection |
| Other features | Arc Correction, Auto Power On, Auto source search, Built-in speaker, Customizable user logo, Daisy chain Multi-Projection, Digital zoom, Direct Power on/off, Document Camera Compatible, Driverless installation, Edge Blending, Email notification, Home Screen, Horizontal and vertical keystone correction, Image Shift, Long light source life, Network administration, OSD copy function, Quick Corner, Schedule Function, Split-Screen-Function, Ultra-wide display (16:6), Web Control, Web Remote, iProjection App |
| Video Color Modes | Blackboard, Cinema, Dynamic, Presentation, sRGB, DICOM SIM, Multi Projection |
| Projector control | via: Crestron Integrated Partner, Crestron RoomView, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol |
| General | |
| Power consumption | 293 Watt - On mode power consumption (Normal) |
| Heat Dissipation | 1,244 BTU/hour (max) |
| Supply Voltage | AC 220 V - 240 V, 50 Hz - 60 Hz |
| Product dimensions | 458 x 375 x 210 mm (Width x Depth x Height) |
| Product weight | 9.4 kg |
| Noise Level | Normal: 36 dB (A) - Economy: 27 dB (A) |
| Supported Temperature | Storage -10° C - 60° C |
| Supported Humidity | Operation 20% - 80%, Storage 10% - 90% |
| Included Software | Epson Creative Projection, EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management |
| Options | Wireless LAN unit |
| Loudspeaker | 8 Watt, Stereo: Stereo |
| What's in the box | |
| Room Type / Application | Signage / Retail, Visitor Attraction |
| Positioning | Ceiling Mounted, Desktop, Wall Mounted |
| Colour | Black |
| Warranty | 60 months Carry in or 12,000 hours |
| Description | Downloads |
|---|---|
| Product Guide | Downloads |
| Datasheet |
