Hikvision Digital Signage Displays combine sleek design with powerful functionality, featuring a slim frame, plastic shell appearance, and an all-in-one design for modern aesthetics. These displays deliver stunning visuals with industrial A+ panels, auto-coloring, and an image-enhancing engine, ensuring exquisite image quality. They support a variety of materials, including static and dynamic content like pictures, audio, video, scrolling subtitles, PDFs, webpages, live video, and more. With flexible program scheduling, users can easily customize playback by day, week, loop, or create unique schedules with multiple materials and playback modes. Centralized management allows remote control of one or more screens, enabling functions like timed startup/shutdown, brightness/volume adjustments, and program updates via USB or remote release. Advanced organizational permissions support a 5-level structure for managing materials, programs, terminals, and users, with customizable user roles and permissions. Multiple security safeguards, including encryption for data storage and transmission, a three-level approval process for materials and schedules, and secure password management, ensure reliable and mistake-free operation.
| Specification | Details |
|---|---|
| Display | |
| Viewing Angle | 178° (H) / 178° (V) |
| Contrast Ratio | 1200:1 |
| Screen Size | 43 inch |
| Active Display Area | 941.184(H) × 529.416(V) mm |
| Backlight | DLED |
| Pixel Pitch | 0.2451(H) × 0.2451(V) mm |
| Resolution | 3840 × 2160 |
| Brightness | 700 cd/m² |
| Color Depth | 1.07G (8 Bits + FRC) |
| Response Time | 8 ms |
| Color Gamut | 72% NTSC |
| Reliability | 7 × 24 H |
| Refresh Rate | 60 Hz |
| Haze | 25% |
| Built-in System | |
| OS | Android 8.0 |
| Processor | A73×2 + A53×2, 1.7 GHz |
| Memory | 3 GB |
| Built-in Storage | 32 GB |
| Interface | |
| Video & Audio Input | DVI-I × 1, HDMI 2.0 × 2, DP 1.2 × 1, Audio Line In × 1 |
| Video & Audio Output | DP 1.2 × 1, Audio Line Out × 1 |
| Network Interface | LAN × 1, Wi-Fi × 1 |
| Data Transmission | USB 2.0 × 2, TF Card × 1 |
| Processing Performance | |
| Decode Capacity | 4K multimedia video, 2 MP video stream |
| Internal Function | |
| Loudspeaker | Built-in speaker (10 W) × 2 |
| Working Environment | |
| Storage Temperature | -20 °C to 60 °C (-4 °F to 140 °F) |
| Storage Humidity | 10% to 90% RH |
| Working Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Working Humidity | 20% to 80% RH |
| General | |
| Material Types | Supports various media formats |
| Power Supply | AC 100V-240V |
| Power Consumption | 110W ± 10% (typical), 225W (max) |
| Standby Consumption | ≿0.5 W |
| Dimensions | |
| Product Dimensions | 973.0 × 561.2 × 63.5 mm |
| Package Dimensions | 1070 × 673 × 141 mm |
| Net Weight | 10.7 kg |
| Gross Weight | 14.4 kg |
| Packing List | Power cord, remote control, manual, warranty card |
