Product Model |
DS-D5C98RB/B |
Display Characteristics |
- Screen Size: 98 inch - Backlight: DLED - Pixel Pitch: 0.5622 × 0.5622 mm |
|
- Resolution: 3840 × 2160 @60 Hz - Brightness: 600 cd/m² (Typ.) |
|
- Color Depth: 10 bit - Display Color: 1.07 G |
|
- Response Time: 5 ms - Panel Type: VA |
|
- Contrast Ratio: 5000:1 (Static), 30,000:1 (Dynamic) |
|
- Color Gamut: 72% NTSC (CIE1931) (Typ.) - Refresh Rate: 60 Hz |
|
- Viewing Angle: 178° (H)/178° (V) - Aspect Ratio: 16:9 |
|
- Surface Hardness: 9H (Pencil) 7 (Mohs) |
|
- Surface Glass: Anti-Glare Glass - Surface Haze: 25% Haze |
|
- Glass Bonding Method: Zero Lamination - Display Area: 2158.848 mm × 1214.352 mm |
|
- Working Duration: 7 × 16 H - Transmittance: 88% ± 3 |
|
- Lifespan: 50,000 hours |
Touch |
- Type: Infrared Touch Screen - Touch Point: Up to 50-point multi-touch |
|
- Touch Response Time: ≤ 2 ms - Minimum Touch Object: ≥ 1.5 mm |
|
- Touch Precision: ± 0.5 mm - Touch Resolution: 32767 × 32767 |
Built-in System |
- Operating System: Android 13.0 - Memory: 8 GB - Built-in Storage: 128 GB |
|
- Processor: Quad-core Cortex-A76 × 4 (2.4 GHz) and Cortex-A55 × 4 (1.8 GHz) |
|
- GPU: Mali-G610 MC4 - HDCP Version: 2.3 |
Camera |
- Pixel: 48 MP for Photos, 8 MP for Video - Camera Resolution Ratio: Up to 4K |
Microphone |
- Specification: Omni-directional 8-array layout - Voice Distance: 12 m |
Internal Function |
- Loudspeaker: Built-in 2 × 20 W+25W - Bluetooth: BLE, supports 5.1 |
|
- NFC: Supports screen mirroring by Android phones - Light Sensor: Yes |
Interface |
- Video & Audio Input: HDMI x 3, VGA x 1, DP x 1, Audio In x 1 |
|
- Video & Audio Output: HDMI Out x 1, Audio Out x 1, SPDIF Out x 1 |
|
- Control Interface: TOUCH-USB 3.0 x 3, RS232 x 1 |
|
- Network Interface: LAN (1000 Mbps) x 2, WiFi 6, 2.4G/5G |
|
- Data Transmission Interface: USB 3.0 x 4, USB 2.0 x 1, Type-C x 2 |
Power |
- Power Supply: 100 to 240 VAC, 50/60 Hz - Standby Consumption: ≤ 0.5 W |
|
- Average Consumption: < 325 W |
General |
- VESA: 1000 mm × 400 mm (4 × M8-20 mm) - Product Dimensions: 2219.8 mm × 1336.4 mm × 105.7 mm |
|
- Accessory: Includes wall mount bracket, touch writing pen, cables, remote control, etc. |
|
- Package Dimensions: 2520 mm × 330 mm × 1700 mm |
|
- Net Weight: 94 kg - Gross Weight: 137 kg |
Working Environment |
- Temperature: 0 °C to 40 °C - Humidity: 10%~90% RH |
