Visualized topology management.
Network health monitor.
Layer 2 features: PoE watchdog, STP/RSTP, VLAN, SNMP, QoS, ERPS, etc.
-30 °C to 65 °C wide temperature range in harsh environment.
| Shell | Metal material | Net Weight | 0.4 kg (0.8 lb) |
| Gross Weight | 1.0 kg (2.2 lb) | Dimensions | 158.00 mm × 101.20 mm × 31.60 mm (6.20'' × 3.90'' × 1.20'') |
| Operating Temperature | -30 °C to 65 °C (-22 °F to 149 °F) | Storage Temperature | -40 °C to 85 °C (-40 °F to 185 °F) |
| Operating Humidity | 5% to 95% (no condensation) | Relative Humidity | 5% to 95% (no condensation) |
| Power Supply | 48VDC, 1.36A | Installation Mode | Desk-Mounted, Rail |
| Max. Power Consumption | 65 W | Idle Power Consumption | 5 W |
| Surge Protection | 6 kV | Ports | 4 × 10/100 Mbps PoE port, 1 × Gigabit RJ45 port, 1 × Gigabit fiber optical port |
| MAC Address Table | 2 K | Switching Capacity | Whole-Device: 14 Gbps; Port: 4.8 Gbps |
| Packet Forwarding Rate | Whole-Device: 10.42 Mpps; Port: 3.57 Mpps | Internal Cache | 1 Mbits |
| PoE Standard | IEEE 802.3af, IEEE 802.3at | PoE Power Pin | 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-) |
| PoE Port | Ports 1 to 4 | Max. Port Power | 30 W |
| PoE Power Budget | 60 W | Long Range | Ports 1 to 4: up to 300 m |
| Long Range Note | Performance may vary depending on camera model or cable condition | Port Isolation | Ports 1 to 4 support isolation mode to improve network security |
| Isolation Function | Ports in an isolation group cannot communicate with each other, but can communicate outside the group | PoE Watchdog | Ports 1 to 4 auto detect and restart unresponsive cameras |
| QoS | Allocates bandwidth for end-to-end service quality assurance | QoS Priority | Supports port-based priority configuration |
| QoS Schedule Mode | SP, WRR priority schedule mode | VLAN | Used for network scale planning and network health improvement |
| VLAN Standard | 802.1Q | VLAN ID Range | 1-4094 |
| VLAN Port Mode | Trunk, Access | Max. VLAN | 4094 VLAN |
| Hik-Partner Pro | One-click activation and remote management | Port Rate Display | Supported |
| Bandwidth Usage Display | Supported | PoE Usage Display | Supported |
| Topology Information | Supported | Alarm Status Display | Supported |
| Port Restart | Supported | Long-Range Mode | Supported |
| Remote Upgrade | Supported | Loop Prevention | Prevents switching network loops; disabled by default |
| STP | 802.1D STP | RSTP | 802.1w RSTP |
| Web Management | Supported | DHCP Client | Enabled by default |
| Super IP | Fixed IP address 10.180.190.200 for direct access | Hik-Central Pro | Management supported |
| Hik-Partner Pro | Remote management supported | Cable Detection | Detects open circuits, short circuits, and cable length |
| LLDP | 802.1ab LLDP peer device discovery | Port Mirroring | Supported for fault locating |
| Port Rate-Limiting | Adjusts port bandwidth to prevent network congestion | Storm Control | Prevents broadcast or multicast storms from blocking switch ports |
| Storm Control Type | Broadcast, multicast, and unknown unicast packets | DHCP Snooping | Prevents unauthorized DHCP servers; disabled by default |
| EMC Approval | CE-EMC (EN 55032:2015+A11:2020, EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020) | Safety Approval | CB (AMD1:2009, AMD2:2013, IEC 62368-1:2014 Second Edition), CE-LVD (EN 62368-1:2014+A11:2017) |
| Chemistry Approval | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No.1907/2006) |
