High Integration Design: The mainboard integrates the control system, Android, network processing, and video interface modules into a single unit, significantly boosting system reliability. It allows flexible plug-and-play module installation for easy setup and maintenance.
Lightweight Solution: Leveraging high-load signal processing technology, the design enables full-screen data transmission using just one internal signal cable.
Innovative Structural Design: Featuring carefully selected Scandinavian-inspired fabric and an ultra-narrow bezel, the product delivers a refined aesthetic. The innovative quick-lock mechanism ensures secure connections with a simple twist, enhancing alignment precision.
Easy and Quick Installation: The cabinet employs a segmented pre-assembly design, facilitating modular column-based installation for quick and efficient setup.
Enhanced Performance: Seamless switching between Android and Windows systems improves adaptability across various scenarios. The WonderOS 3.0 system is optimized for large-screen UI interactions, providing an intuitive user experience.
Versatile Functionality: Supports multi-device wireless screen sharing, conference recording, welcome message display, and other practical features for diverse applications.
| Product Model | DS-D4515CB135-2FQ | Pixel Configuration | SMD Triad LED (with glue) |
| Pixel Pitch | 1.5625 mm | Resolution | 1920 × 1080 |
| Pixel Density | 409600 dots/m² | Cabinet Material | Aluminum alloy |
| Pixel Pitch Category | P1.5 | Maintenance Method | Front maintenance |
| White Balance Brightness | 600 cd/m² | Color Temperature | 3000–10000 K adjustable |
| Viewing Angle | 160° (H) / 160° (V) | Brightness Uniformity | ± 0.003 Cx, Cy |
| Color Uniformity | ≥ 97% | Screen Size | 135 inch (344.1 cm) |
| Contrast Ratio | 3000:1 | Active Screen Area | 5.0 m² |
| Display Ratio | 16:9 | Optimal View Distance | 3 m |
| Operating System | Android 12; Windows 10 optional with OPS accessories | CPU | Android: Max. 1.5 GHz, A76 × 4 + A55 × 4 Windows: i5-11390H |
| Memory | Android: 16 GB Windows: 16 GB |
Built-in Storage | Android: 256 GB Windows: 256 GB |
| NIC | Integrated gigabit LAN with router mode enabled | CPU Clock Speed | 2.4 GHz |
| Wireless | Supports concurrent operation in station and access point (AP) mode, enabling Wi-Fi hotspot functionality. | Bluetooth | Integrated BLE module compliant with Bluetooth 5.1 and backward-compatible versions. |
| Video & Audio Input | LINE IN × 1, HDMI IN × 4 | Video & Audio Output | LINE OUT × 1, SPDIF OUT × 1, HDMI OUT × 1 |
| Data Transmission Interface | Front Panel Interfaces: USB 3.0 × 2, Type-C × 1 Internal Slot at Bottom: USB 2.0 × 1 |
Control Interface | 1 × RS232 serial port |
| Speaker | Built-in 2 × 18 W speaker | Driving Method | Constant current driving |
| Frame Frequency | 30 Hz / 60 Hz | Refresh Rate | 3840 Hz |
| Grey Level | 16 bit | Power Specification | 4.2 V / 40 A (Cabinet Power Supply), 19 V / 8 A (Control Power Supply) |
| Standby Consumption | ≤ 0.5 W | Short Circuit | 220 V, 20 A |
| Maximum Consumption | ≤ 2000 W | Average Consumption | ≤ 670 W |
| Input Voltage | 110–240 VAC, 50/60 Hz (110 V with Low-Voltage Power Cord) | Working Temperature | -10 to 40°C (14 to 104°F) |
| Working Humidity | 20% to 80% RH (non-condensing) | Storage Temperature | -10 to 50°C (14 to 122°F) |
| Storage Humidity | 10% to 90% RH (non-condensing) | Product Dimensions (W × H × D) | With Base: 3011.5 (W) mm × 2470.1 (H) mm × 733.58 (D) mm Without Base: 3011.5 (W) mm × 1813.3 (H) mm × 47.1 (D) mm Screen Size: 3000 (W) mm × 1687.5 (H) mm |
| Mounting Type | Wall Mounting / Mobile Floor Standing Bracket Mounting (Packaging includes wall-mount bracket by default.) | Packing Method | 1 wooden case package |
| Net Weight | 144.0 kg (317.47 lb.) | Package Dimensions (W × H × D) | 3011.5 (W) mm × 2470.1 (H) mm × 733.58 (D) mm (118.56" × 97.25" × 28.88") |
| Packing List | LED Module Spare Parts × 4, Multilingual Manual × 1, Bottom Panel Connector × 1, Wall Mounting Bracket × 1, Cables (OPS Power Cable, OPS Signal Cable, Main Power Cable, Ethernet Cable, Cabinet Cascade Power Cable), Accessories (Lamps, IC, Screws, Expansion Bolt, Tools, etc.) | Indicator | Red: The device is standby. Blue: The device is powered on. |
| Button | On/Off/Sleep button × 1 | Modular Bracket | Floor-standing Bracket: DP-D40XCB22-5X5-Q5-NS-Q6-ZY/135 |
| Description | Downloads |
|---|---|
| Datasheet | Download |
| User Manual | Download |
| Dimensions | Download |
