Hikvision DS-D4518CB162-2FQ 162" P1.8 Non-Touch LED Display
SKU: DS-D4518CB162-2FQ
£13,332.00 (Excl. VAT)
- Description
- Specifications
- Downloads
-
Large-Format Visual Solution for Enterprise Collaboration
High Integration Design: The mainboard integrates the control system, Android, network processing, and video interface modules into a single unit, significantly boosting system reliability. It allows flexible plug-and-play module installation for easy setup and maintenance.
Lightweight Solution: Leveraging high-load signal processing technology, the design enables full-screen data transmission using just one internal signal cable.
Innovative Structural Design: Featuring carefully selected Scandinavian-inspired fabric and an ultra-narrow bezel, the product delivers a refined aesthetic. The innovative quick-lock mechanism ensures secure connections with a simple twist, enhancing alignment precision.
Easy and Quick Installation: The cabinet employs a segmented pre-assembly design, facilitating modular column-based installation for quick and efficient setup.
Enhanced Performance: Seamless switching between Android and Windows systems improves adaptability across various scenarios. The WonderOS 3.0 system is optimized for large-screen UI interactions, providing an intuitive user experience.
Versatile Functionality: Supports multi-device wireless screen sharing, conference recording, welcome message display, and other practical features for diverse applications.
-
Product Model DS-D4518CB162-2FQ Pixel Configuration SMD Triad LED (with glue) Pixel Pitch 1.875 mm Resolution 1920 × 1080 Pixel Density 284444 dots/m² Cabinet Material Aluminum alloy Pixel Pitch Category P1.8 Maintenance Method Front maintenance White Balance Brightness 600 cd/m² Color Temperature 3000–10000 K adjustable Viewing Angle 160° (H) / 160° (V) Brightness Uniformity ± 0.003 Cx, Cy Color Uniformity ≥ 97% Screen Size 162 inch (413.0 cm) Contrast Ratio 3000:1 Active Screen Area 7.3 m² Display Ratio 16:9 Optimal View Distance 3 m Operating System Android 12; Windows 10 optional with OPS accessories CPU Android: Max. 1.5 GHz, A76 × 4 + A55 × 4
Windows: i5-11390HMemory Android: 16 GB
Windows: 16 GBBuilt-in Storage Android: 256 GB
Windows: 256 GBNIC Integrated gigabit LAN with router mode enabled CPU Clock Speed 2.4 GHz Wireless Supports concurrent operation in station and access point (AP) mode, enabling Wi-Fi hotspot functionality. Bluetooth Integrated BLE module compliant with Bluetooth 5.1 and backward-compatible versions. Video & Audio Input LINE IN × 1, HDMI IN × 4 Video & Audio Output LINE OUT × 1, SPDIF OUT × 1, HDMI OUT × 1 Data Transmission Interface Front Panel Interfaces: USB 3.0 × 2, Type-C × 1
Internal Slot at Bottom: USB 2.0 × 1Control Interface 1 × RS232 serial port Speaker Built-in 2 × 18 W speaker Driving Method Constant current driving Frame Frequency 30 Hz / 60 Hz Refresh Rate 3840 Hz Grey Level 16 bit Power Specification 4.2 V / 40 A (Cabinet Power Supply), 19 V / 8 A (Control Power Supply) Standby Consumption ≤ 0.5 W Short Circuit 220 V, 20 A Maximum Consumption ≤ 3000 W Average Consumption ≤ 1000 W Input Voltage 110–240 VAC, 50/60 Hz (110 V with Low-Voltage Power Cord) Working Temperature -10 to 40°C (14 to 104°F) Working Humidity 20% to 80% RH (non-condensing) Storage Temperature -10 to 50°C (14 to 122°F) Storage Humidity 10% to 90% RH (non-condensing) Product Dimensions (W × H × D) With Base: 3611.4 (W) mm × 2807.82 (H) mm × 733.5 (D) mm
Without Base: 3611.4 (W) mm × 2150.7 (H) mm × 47.1 (D) mm
Screen Size: 3600 (W) mm × 2025 (H) mmMounting Type Wall Mounting / Mobile Floor Standing Bracket Mounting (Packaging includes wall-mount bracket by default.) Packing Method 1 wooden case package Net Weight 211.7 kg (466.72 lb.) Package Dimensions (W × H × D) 3611.4 (W) mm × 2807.82 (H) mm × 733.5 (D) mm (142.18" × 110.54" × 28.88") Packing List LED Module Spare Parts × 4, Multilingual Manual × 1, Bottom Panel Connector × 1, Wall Mounting Bracket × 1, Cables (OPS Power Cable, OPS Signal Cable, Main Power Cable, Ethernet Cable, Cabinet Cascade Power Cable), Accessories (Lamps, IC, Screws, Expansion Bolt, Tools, etc.) Indicator Red: The device is standby.
Blue: The device is powered on.Button On/Off/Sleep button × 1 Modular Bracket Floor-standing Bracket: DP-D40XCB22-6X6-Q7-NS-Q9-ZY/162 -
Description Downloads Datasheet Download User Manual Download Dimensions Download
