23.8 VA 75Hz Monitor
Ultra-thin device body with ultra-thin border for 3 sides.
8 bit LVDS HD (1920 × 1080) display.
178° ultra-wide view screen.
3D noise reduction.
Low blue light design for eye care.
Dual interface of HDMI and VGA.
Support VESA wall mount.
Built-in speaker for audio input.
| Screen Size | 23.8 inch | Active Display Area | 527.04 mm (H) × 296.46 mm (V) |
| Resolution | 1920 × 1080 | Backlight | E-LED |
| Pixel Pitch | 0.2745 (H) mm × 0.2745 (V) mm | Brightness | 250 cd/m² |
| Viewing Angle | 178° (H) / 178° (V) | Color Depth | 8 bit |
| Contrast Ratio | 4000 : 1 | Response Time | 6.5 ms (typ) |
| Refresh Rate | Max. 75Hz, Typ. 60 Hz | Haze | Haze 25%, 3H |
| Reliability | 7 × 24 H | Color Gamut | 72% NTSC |
| Video & Audio Input | HDMI 1.4 × 1, VGA × 1, BNC（CVBS） × 1, AUDIO IN × 1 | Video & Audio Output | Speaker (2W 4Ω) × 2 |
| Data Transmission Interface | USB 2.0 (support program upgrade and USB online playback) × 1 | Power Supply | AC 100-240V～, 50/60Hz, 0.5A Max |
| Power Consumption | ≤ 25W | Standby Consumption | ≤ 0.5 W |
| Working Temperature | 0℃ to 40 ℃ (32 ℉ to 104 ℉) | Working Humidity | 10% ~ 80% RH (Non-Condensing) |
| Storage Temperature | -20 ℃ to 60 ℃ (-4 ℉ to 140 ℉) | Storage Humidity | 5%~90% RH (Non-Condensing) |
| Casing Material | Plastic | VESA | 75 mm × 75 mm (4-M4 × 6 mm) |
| Bezel Width | 1.75 mm (top/left/right), 23.55 mm (bottom) | Product Dimensions Without Stand | 539.1 (W) mm × 327.04 (H) mm × 41.78 (D) mm（21.22″ × 12.88″ × 1.64″） |
| Product Dimensions With Stand | 539.1 (W) mm × 433.2 (H) mm × 209.99 (D) mm（21.22″ × 17.06″ × 8.27″） | Package Dimensions | 652 (W) mm × 445 (H) mm × 116 (D) mm（25.67″ × 17.52″ × 4.57″） |
| Net Weight | 3.32 ± 0.5 kg | Gross Weight | 4.66 ± 0.5 kg |
| Packing List | Monitor × 1, Base component × 1, AC power cable (1.5 m) × 1, HDMI cable (1.5 m) × 1, User manual × 1, Multilingual manual × 1 | Remarks | If the appearance and parameters in this specification vary from the actual product, the later prevails. You can also consult local sale staff. |
| Description | Downloads |
|---|---|
| Datasheet | Download |
