Official Partner
UHD 4K display with a resolution of 3840 × 2160 and 480 nits brightness.
Anti-glare and anti-blocking design to ensure smooth interaction.
Dual systems of Android and Windows (optional with 195×30×180mm OPS) saving cost and easy to use, video conferencing software is recommended to run on the Windows system.
Quick response, at most 50-point touch control and smooth writing experience.
Built-in network switch chip eliminates the need for an external network switch.
Multi-button front design for convenient classroom use.
All-in-one design with tempered glass and intelligent temperature control, making it environmentally friendly and safety-guaranteed.
Built-in Android 14 system, EDLA certified.
Dual full-function USB Type-C ports, supporting up to 100W total power delivery and DisplayPort 1.2 input.
Built-in sensors for light, humidity, and temperature monitoring.
| Section | Display | Screen Size | 86 inch |
| Backlight | DLED | Pixel Pitch | 0.164 (H) × 0.493 (V) mm |
| Resolution | 3840 × 2160 @60 Hz | Brightness | 480 cd/m² (Typ.) |
| Color Depth | 10 bit (8 bit + FRC) | Display Color | 1.07 G |
| Response Time | 5 ms | Panel Type | VA |
| Contrast Ratio | 5000:1 (Static) 30,000:1 (Dynamic) | Color Gamut | 72% NTSC (CIE1931) (Typ.) |
| Refresh Rate | 60 Hz | Viewing Angle | 178° (H)/178° (V) |
| Aspect Ratio | 16:9 | Surface Hardness | 9H (Pencil) 7 (Mohs) |
| Surface Glass | Anti-Glare & Anti-Fingerprint glass | Surface Haze | 25% Haze |
| Glass Bonding Method | Zero Lamination | Display Area | 1895.04 (H) × 1065.96 (V) |
| Working Duration | 7 × 16 H | Transmittance | 88% ± 3 |
| Lifespan | 50,000 hours | Section | Touch |
| Type | Infrared Touch Screen | Touch Point | Up to 50-point multi-touch |
| Touch Response Time | ≤ 2 ms | Minimum Touch Object | ≥ 1.5 mm (≥ 90% touching area) |
| Touch Precision | ± 0.5 mm (≥ 90% touching area) | Touch Resolution | 32768 × 32768 |
| Section | Built-in System | Operation System | Android 14.0 |
| Memory | 8 GB | Built-in Storage | 128 GB |
| Processor | Quad-core Cortex-A76 × 4（2.4 GHz）and quad-core Cortex-A55 × 4（1.8 GHz） | GPU | Mali-G610 MC4 |
| HDCP Version | 2.3 & 2.0 & 1.4 | Section | Internal Function |
| Loudspeaker | Built-in 2 × 20 W + 25 W loudspeaker; | Bluetooth | Built-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.4 |
| NFC | Support card reader 13.56 MHz, (ISO 14443A/ ISO 14443B/ ISO 15693) | Light Sensor | Yes |
| Humidity and Temperature Sensor | Relative humidity accuracy: up to ± 1.5 %RH; Temperature accuracy: up to ± 0.1 °C | Section | Interface |
| Video & Audio Input | HDMI 2.1 TMDS × 3（Front x 1; Rear x 2; Support HDCP2.3 & 2.0 & 1.4; Support HDMI CEC protocol） VGA × 1（Rear） Audio × 1（Rear） | Video & Audio Output | HDMI 2.1 TMDS × 1（Rear） Audio × 1（Rear） SPDIF × 1（Rear） |
| Control Interface | TOUCH-USB 3.0 × 1（Front × 1） TOUCH-USB 2.0 × 2（Rear × 2） RS232 × 1（Rear） | Network Interface | LAN (1000 Mbps) × 2（Rear） Wi-Fi AP & Station, 2.4 G/5 G Wi-Fi 6, IEEE 802.11 a/b/g/n/ac/ax 2 × 2 MIMO (2.4 GHz and 5 GHz) authentication protocols WEP, WPA, WPA2, PSK and 802.1X EAP |
| Data Transmission Interface | USB 3.0 × 4（Front × 2; Rear × 2） USB 2.0 × 1（Rear） Type-C × 2 (Front × 1; Rear × 1; Support USB 2.0, 100 W charging functions, DP IN 1.2 ) | Section | Power |
| Power Supply | 100 to 240 VAC, 50/60 Hz | Standby Consumption | ≤ 0.5 W |
| Average Consumption | < 274 W | Section | Working Environment |
| Working Temperature | 0 °C to 40 °C (32 °F to 104 °F) | Working Humidity | 10%~90% RH |
| Section | General | VESA | 800 mm × 600 mm (4 × M8-25 mm) |
| Accessory | Wall mount bracket, hook, user manual, touch writing pen, packing list, 3 M touch USB cable, 3.5 M HDMI cable (2.0), 3 M power cable, remote control, screen cleaning cloth. | Package Dimensions (W × H × D) | 2157 × 1345 × 223 mm |
| Net Weight | 58.5 ± 0.5 kg | Gross Weight | 78.5 ± 0.5 kg |
| Product Dimensions （With Wall Attachment） | 1960.4 × 1158.2 × 114.5 mm | Product Dimensions （Without Wall Attachment） | 1960.4 × 1158.2 × 82.5 mm |
| Description | Downloads |
|---|---|
| Datasheet | Download |
| User Manual | Download |
| Dimensions | Download |
