Support Windows/Mac OS.
Type-C interface plug-and-play.
Support Wi-Fi 2.4G/5G dual frequency.
Support up to 4K resolution.
Support reverse control by Windows/Mac.
Add NFC module to support NFC screen mirroring with Android phones.
Support indirectly charge for laptops.
Support quick screen mirroring on Hikvision Interactive Flat Panel.
| Product Model | DS-D5SC3B-W | Resolution | 1080P/4K |
| Memory | 512 MB | Built-in Storage | 4 GB |
| Net Card | Built in Gigabit NIC, supporting 2.4G/5G. | Power Interface | Typc-C, support CC communication and automatically switch charging direction, achieving 60W fast charging for laptops by adapter and 5V/500mA charging for mobile phones from laptops. |
| Power Consumption | 2.8 W | Rated Power | 5 V/900 mA |
| Working Temperature | 0℃~40℃ | Working Humidity | 10%~95% RH |
| Product Dimensions | 189 × 58 × 17 mm | Package Dimensions (W × H × D) | 235 × 90 × 30 mm |
| Net Weight | 90 g | Gross Weight | 210 g |
| Packing List | Host × 1, Manual × 1, USB Type-A/Type-C adapter × 1 | Frame Rate | 30 fps |
| Transmission Delay | ≤ 350 ms | Wireless Transmission Protocol | IEEE 802.11 a/g/n/ac |
| Encryption | AES | NFC | ISO/IEC 14443-A protocol, 13.56 MHz, 106 Kbps |
| Audio Parameters | 48000Hz sampling rate, 16 bit depth, ACC encoding, dual channel | Video Parameters | 10 bit color depth, H.264 encoding format |
| USB Protocol | Support USB 2.0 |
| Description | Downloads |
|---|---|
| Datasheet | Download |
| User Manual | Download |
