Hisense All Weather Digital Signage Display’s are ideal for any retail and business environments. Our 2500nit high-bright screen provides clear content ensuring maximum engagement in any lighting conditions. The IP65 Air Conditioned cooled enclosure protects components in any conditions all year round with no filter maintainance required.
Visible With Polarized Sunglasses
LED display correction technology could uniformly lighten several hundred thousand LED lights, presenting a uniform display effect with the same brightness and color scale.
Smart Brightness Sensor
Self-heat dissipation design, energy saving and noise reduction improve the service life.
IP Rated All Weather Displays
The IP rating provide full protection against dust and water projection. Built in intelligent heating and cooling, together with a smart automatic air circulation system. Anti vandal glass for protection from extreme environmental conditions and impacts to the display.
Efficient Heat Dissapation Management
Professional software for thermal simulation for cooling system design, which cools down the heat generated from every part of the product with high performance, preventing outside air from entering.
Easy Maintenance
Telecom-class routing design ensures the cabinet sealing performance. Front door access with lock for both wall mount monitor and kiosk models for easy operation and maintenance.
Safety Lock and Invisible Screws and Hinges
With Professional three-point anti-theft lock design, internal locking of bolts, no exposed high-strength steel doors, Hisense Outdoor Display can prevent criminals from picking locks and doing malicious damage.
| General | Details |
|---|---|
| Screen Size | 49“ |
| Screen Active Area (mm) | 1074 x 604 |
| Resolution | FHD (1920 x 1080) |
| Aspect Ratio | 16:9 |
| Brightness (nit) | 2500nits |
| Contrast Ratio | 1200:1 |
| Viewing Angle (H/V) | 178°/178° |
| Backlight Life Cycle | 50,000 Hrs |
| Operation Hours | 24/7 |
| Response Time | 8ms |
| Screen Orientation | Portrait |
| Touchscreen (Option) | |
| Touch Type | P-CAP (projective capacitive) |
| Touch Point | 10-points |
| Response Time | ≤10ms |
| System | |
| OS | Android 7.1 |
| CPU | Amlogic Quad-core Cortex-A53,1.5GHz |
| GPU | Mali-450 |
| DDR | 2G DDR4 |
| ROM | 16G EMMC (support expanded memory card up to 128G) |
| Language | Chinese/English |
| Connectivity | |
| Input | x2 HDMI IN/ x1 USB2.0/ x1 LAN x1 TF card slot/ x1 RS232 |
| Output | x1 HDMI OUT/ x1 AV OUT |
| Network connection | Wifi or LAN: Yes |
| 3G/4G Connection | Optional |
| Speaker | |
| Built-in Speaker | Yes |
| Thermal Management | |
| Built-in air conditioner | Air conditioner |
| Overheating Protection | Yes |
| Physical | |
| IP Rating | IP65 |
| Glass | 6.8 mm (AR, Tempered & Laminated Glass) |
| Metal | Galvanized steel with powder coated |
| Standard Color | Black |
| Dimensions | 2000(H) x 780(W) x 255(D) mm |
| Net Weight | 180kg |
| Packing Dimensions | 2180(H) x 880(W) x 500(D) mm |
| Operation | |
| Working Environment | Full outdoor |
| Auto Brightness Control | Light sensor |
| Operation Temperature | -40℃ to 55℃ |
| Operation Humidity | 5% to 95% |
| Power | |
| Power Supply | AC 110 /220V,50/60Hz |
| Power Type | Built-In Power |
| Power Consumption | 650W(Max.) |
| Available Regions | |
| EU | |
| APAC | |
| SA |
| Document Type | Download Link |
|---|---|
| 49SOA25PT Datasheet | DOWNLOAD |
