Large 65-inch canvas
Ideal where promotions, menus, dashboards and corporate messaging need to remain clear across deeper rooms and wider spaces.
Official Partner
iiyama LH6560UHS-B2AG 65" 4K Commercial Digital Signage Display
65"Display size
Ultra HD (4K)Resolution
VA PanelPanel
Android 11Operating system
USB Plug and PlayPlayer features
3 Year WarrantyWarranty
In Stock23 available
Express DeliveryFast UK delivery where eligible
3 Year WarrantyManufacturer-backed cover
UK Expert SupportPre-sales and technical advice
Product description
Large-format professional signage
iiyama ProLite LH6560UHS-B2AG 65" 4K Commercial Display
A slim 65-inch professional digital signage display with 4K resolution, 500 cd/m² brightness, Android 11, iiSignage² and dependable 24/7 operation. Built for retail, corporate, hospitality, education and public-facing environments.
LH6560UHS-B2AG
Why this model
High-impact 65-inch signage without an oversized chassis
The LH6560UHS-B2AG combines a large 64.5-inch panel with a slim 38.9 mm profile, helping it deliver stronger visual presence without appearing bulky. It is best suited to larger rooms, lobbies, retail walls, menu-board installations and public information points.
4K Ultra HD resolution
3840 × 2160 resolution keeps text, product visuals, video and presentations crisp across the larger panel.
500 cd/m² brightness
Suitable for well-lit indoor commercial locations such as retail, hospitality, education and workplace environments.
24/7 operation
Designed for continuous professional use, with fanless operation and anti-image-retention support.
Android 11 and iiSignage²
Run compatible applications directly on the display and manage scheduled content remotely.
Portrait or landscape
Mount horizontally or vertically. A VESA 400 × 400 mm wall mounting kit is included.
Best fit
Built for larger rooms and stronger viewing distances
A 65-inch display works particularly well where viewers are typically around 3 to 6 metres away. It provides more impact than a 55-inch panel while remaining practical for wall-mounted commercial installations.
- Retail feature walls and showrooms
- Hotel lobbies and reception spaces
- Larger meeting and presentation rooms
- Digital menu boards and hospitality venues
- Education and public information displays
- Portrait directories and wayfinding
Technical overview
Key specifications at a glance
Panel64.5" VA, anti-glare, 25% haze
Resolution3840 × 2160 at 60 Hz
Brightness500 cd/m²
Contrast5000:1 static
Inputs3 × HDMI 2.0, 2 × USB 2.0
ControlRS-232C and RJ45 LAN
Audio2 × 10 W speakers
WirelessBuilt-in 802.11ac Wi-Fi
OrientationLandscape and portrait
MountingVESA 400 × 400 mm
Dimensions1459.2 × 837.1 × 38.9 mm
Weight25.3 kg without box
View complete technical specifications
| Category | Details |
|---|---|
| Design | Thin bezel |
| Screen Size | 64.5", 164 cm |
| Panel Type | VA, Anti-Glare Coated Glass, Hard Coating (3H), haze 25% |
| Resolution | 3840 x 2160 (4K UHD) @ 60Hz |
| Aspect Ratio | 16:9 |
| Brightness | 500 cd/m² |
| Contrast Ratio | 5000:1 static |
| Response Time | 6.5ms (GTG) |
| Viewing Angles | horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89° |
| Colour Support | 1.07G (8 Bits+FRC) (NTSC 87%) |
| Horizontal Sync | 28 - 160kHz |
| Pixel Pitch | 0.372mm |
| Viewable Area (W x H) | 1428.5 x 803.5 mm (56.2 x 31.6") |
| Bezel Width | 14mm, 14mm, 16mm (sides, top, bottom) |
| Bezel Colour and Finish | black, matte |
| Inputs | HDMI x3 (2.0, max. 3840x2160 @60Hz), RS-232c x1, RJ45 (LAN) x1 |
| Audio Out | 3.5mm mini jack |
| Speakers | 2 x 10W |
| USB Ports | 2x USB 2.0 |
| HDCP | 1.4 & 2.2 |
| Integrated Software | Android 11 OS, FailOver, iiSignage², EShare |
| Wi-Fi | Yes (802.11ac built-in) |
| Processor | CPU: A53 x4, GPU: G52 MP2, RAM: 2GB, ROM: 16GB |
| Extra | Wall mounting kit included (VESA 400 x 400mm) |
| Max Runtime | 24/7 continuous use |
| Anti Image Retention | Yes |
| Media Playback | Yes |
| Housing Material | Metal (front) |
| OSD Languages | EN, DE, FR, ES, IT, CN, RU, JP, CZ, NL, PL, SV, FI, DA, NB |
| Control Buttons | Power button, Power Indicator, Remote Sensor |
| User Controls | Picture (brightness, contrast, sharpness, black level, tint, colour, noise reduction, gamma selection, colour temperature, colour control, over scan, picture reset); Screen (zoom mode, custom zoom, screen reset); Audio (balance, treble, bass, volume, audio out, maximum volume, minimum volume, mute, audio out sync, speaker setting, audio reset); Configuration 1 (switch on state, panel saving, RS232-routing, boot on source, WOL, configuration 1 reset, factory reset); Configuration 2 (OSD timeout, OSD H-Position, OSD V-position, system rotation, information OSD, logo and animation logo setting, animation setting, monitor ID, monitor information, HDMI version, configuration 2 reset); Advanced option (IR control, off timer, schedule, HDMI with one wire, HDMI with one wire power off, FailOver, language, OSD transparency, power saving, advanced option reset); Android settings (network & internet, apps & notifications, display, signage display, security, language & input, date & time, about device) |
| Plug&Play | DDC2B |
| Orientation | Landscape / Portrait |
| Fanless Design | Yes |
| VESA Mounting | 400 x 400 mm |
| Operating Temp. | 0°C to 40°C |
| Storage Temp. | -20°C to 60°C |
| MTBF | 50,000 hours (excluding backlight) |
| Included Accessories | Power cable (1.8m), HDMI cable (1.8m), RS-232c cable (1.8m); quick start guide; safety guide; wall mount bracket; wall mount guide; screws; screw anchors; stickers for screw holes; remote control with batteries |
| Power Supply Unit | Internal |
| Power Supply | Internal, AC 100 - 240V, 50/60Hz |
| Energy Star 8.0 (POn at 230V) | 70.97W |
| Power Usage | 59W typical, 0.5W standby, 0.3W off |
| Energy Class | C (Regulation (EU) 2017/1369) |
| Regulations | CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, UKCA |
| REACH SVHC | Above 0.1%: Lead, Lead monoxide, Diboron trioxide |
| Product Dimensions | 1459.2 x 837.1 x 38.9 mm |
| Box Dimensions | 1640 x 990 x 164 mm |
| Weight (without box) | 25.3 kg |
| Weight (with box) | 36.4 kg |
| EAN Code | 4948570124459 |
Documents
Manuals, labels and technical downloads
Document
User Manual
Document
Technical Specification
Document
Product Drawing
Document
EU Energy Label
Document
UK Energy Label
Document
EShare Network Requirements
Document
RS-232 / LAN Commands
Document
CE Declaration of Conformity
Buying guidance
Frequently asked questions
Can the LH6560UHS-B2AG run 24/7?
Yes. It is rated for continuous 24/7 commercial operation.
Does it include Android?
Yes. Android 11 is built in, together with Wi-Fi, 2 GB RAM and 16 GB internal storage.
Can it be mounted vertically?
Yes. The display supports both portrait and landscape installation.
Is a wall mount included?
Yes. A wall mounting kit is included for the 400 × 400 mm VESA pattern.
Is 500 cd/m² suitable for shop windows?
It is suitable for bright indoor locations, but direct-facing shop windows normally require a specialist high-brightness display.
What viewing distance suits a 65-inch display?
For many commercial applications, approximately 3 to 6 metres is suitable, depending on text size, mounting height and content detail.
What is the EAN?
The EAN code is 4948570124459.
Can Screen Moove install it?
Yes. Screen Moove can support mounting, installation, CMS setup and multi-site deployment across the UK.
Project support
Need a complete 65-inch signage package?
Send the quantity, installation location, wall type, viewing distance and required completion date. Screen Moove can specify the display, mount, CMS and installation package.
Technical specifications
- Display size / Screen sizes
- 65"
- Resolution
- Ultra HD (4K)
- Panel type
- VA Panel
- Screen type
- Flat
- Brightness
- 500 cd/m2
- Screen ratio
- 16:9
- Refresh rate
- 60Hz
- Display orientation
- Landscape & Portrait
- Operating hours
- 24/7
- Operating system
- Android 11
- Player features
- USB Plug and Play
- VESA patterns
- 400x400
- Warranty
- 3 Year Warranty
iiyama LH6560UHS-B2AG 65" 4K Commercial Digital Signage DisplaySKU: LH6560UHS-B2AG
£740.47
