24” Full HD In-cell PCAP 10pt interactive Touch Panel PC with Android OS, IPS panel technology, anti glare coating, PoE Technology and iiSignage²
The ProLite TW2424AS-B3P interactive Touchpanel-PC is a perfect choice for high-use environments. The IPS panel, integrated in a slim and elegant bezel, delivers both excellent colour performance with wide viewing angles and noticeably sharper images. The In-cell 10tp PCAP touch technology ensures a fluid and natural touch experience. This monitor can operate in landscape, portrait and face-up orientation in 24/7 operating time. Thanks to the pre-installed Android 14 operating system, it is possible to easily customize the monitor by installing applications directly to it. In combination with the 32GB storage, Wi-Fi connection, LAN (RJ45) and Bluetooth connectors, it makes the monitor especially suited for POS systems or information points in retail shops to educate customers about your products, as well as virtually limitless smart home applications. Thanks to Power over Ethernet (PoE), both power and data are delivered through a single cable, simplifying installation and reducing additional cables.
Additionally, it integrates effortlessly with iiSignage², iiyama’s Content Management System (CMS), giving you full control over your messages and advertising.
Connectivity
The RJ45 (LAN) connector supporting Power over Ethernet technology (POE) allows to provide both data connection and power by a single cable, which simplifies installation in areas where many cables would interfere with the environment.
Android OS
Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.
iiSignage²
iiSignage² is our digital signage content management platform to easily show and control your content and to manage your displays in a secure way. The Content Management System (CMS) gives you total control of your messaging and advertising remotely and safely.
| Design | Thin bezel | Diagonal | 23.8", 60.5cm |
| Panel | IPS | Native Resolution | 1920 x 1080 (2 megapixel HD) |
| Aspect Ratio | 16:9 | Brightness | 450 cd/m² with touch |
| Static Contrast | 1000:1 with touch | Response Time (GTG) | 14ms |
| Viewing Zone | 178°/178°, right/left: 89°/89°, up/down: 89°/89° | Colour Support | 16.7 million, 8bit |
| Horizontal Sync | 31 - 83kHz | Viewable Area (W x H) | 527 x 296.5mm |
| Pixel Pitch | 0.275mm | Bezel Colour / Finish | Black, matte |
| Touch Technology | Projective capacitive | Touch Points | 10 (HID, integrated OS only, external OS supports single touch) |
| Touch Method | Finger, glove (latex), capacitive stylus | Touch Interface | USB |
| Audio Input | Mini jack x1 | Digital Signal Output | USB-C x1 (v3.2 Gen 1, video output and touch board function) |
| Audio Output | Speakers 2 x 5W | HDCP | Yes |
| USB Ports | 2 (1x USB 3.2 Gen 1, 1x USB 2.0) | RJ45 (LAN) | 1 (PoE - IEEE802.3at/72W, 1000M) |
| Microphone | 1 | Integrated Software | Android 14 with GMS |
| SOC | Octa-core RK3576 (4x A53 + 4x A72) | GPU | ARM G52 MC3 |
| Storage | 32GB eMMC | Memory | 4GB LPDDR4 |
| WiFi | IEEE802.11ax/ac/a/b/g/n | Bluetooth | 5.3 |
| Extra Features | Auto-rotation, 2x5W speakers, dual microphone, anti-glare coating, PoE, iiSignage² | Max Operating Time | 24/7 |
| Anti Image Retention | Yes | Glass Hardness | 6H |
| OSD Key Lock | Yes | Control Buttons | Power switch, volume +, volume - |
| Applications | Lock application, restart scheduler, power scheduler, calculator, calendar, Chrome, alarm, file manager, Gmail, Google, iiSignage², Play Store, recorder, video player | Flicker Free | Yes |
| Orientation | Landscape, portrait, face-up | VESA Mounting | 100 x 100mm |
| Cable Management | Yes | MTBF | 50000 hours (excluding backlight) |
| Included Cables | Power cable (1.8m) | Guides Included | Quick start guide, safety guide |
| Other Included | AC adapter | Cable Cover | Yes |
| Power Supply Unit | External | Power Supply | DC 12V |
| Power Usage | 17.5W typical, 0.5W standby, 0.3W off mode | Regulations | CE, EAC, RoHS, ErP, WEEE, REACH, UKCA |
| REACH SVHC | Above 0.1%: Lead | Product Dimensions (W x H x D) | 550 x 336 x 28mm |
| Box Dimensions (W x H x D) | 640 x 410 x 121mm | Weight (Without Box) | 4.24kg |
| Weight (With Box) | 6.2kg | EAN Code | 4948570127153 |
| Description | Downloads |
|---|---|
| iiyama ProLite TW2424AS-B3P 24″ Full HD PCAP 10pt Android Touch Panel SpecSheet | Download |
| iiyama ProLite TW2424AS-B3P 24″ Full HD PCAP 10pt Android Touch Panel User Manual | Download |
| iiyama ProLite TW2424AS-B3P 24″ Full HD PCAP 10pt Android Touch Panel Drawing | Download |
