4 Output Video Wall Driver
VW−4 is a 4−output video wall driver designed to quickly and easily configure and manage video walls. Use one VW−4 device to create any wall configuration with up to 4 displays, for example, a 2x2, 4x1, 1x4, 2x1, 3x1 video wall. Connect additional devices to create walls of any size and configuration of up to 64 displays. Configure a single or multiple device setup using the VW−4 app via Ethernet or RS−232, or quickly configure a basic setup using the local dip switches.
Scalable Video Walls
Create and manage a video wall of up to 4 displays or, by adding devices, create video walls of up to 64 displays.
Quick, Basic, Local Setup
Use front panel DIP–switches for basic setup of video walls up to 16 displays.
Full Feature Configuration
Use the VW–4 app via Ethernet or RS–232 to set up video walls of up to 8x8 displays. Also use the app for the following: bezel corrections, HDCP status, factory reset, upgrading firmware, viewing network settings and copying EDID.
Content Protection
Supports HDCP 2.2 on the input and loop output and HDCP 1.4 on the main outputs. HDCP can be disabled on the input.
EDID Support
Upload EDID files, copy any output EDID to the input, and select from several built–in EDID files.
Reliable Video
Features constant output sync and auto–sync off option that stops or delays the 5V shutoff when no input is detected.
Auto Display Powering
CEC capabilities turn ON or OFF the connected displays according to the status of the input video.
Easy Installation
Compact MegaTOOLS® fan–less enclosure for surface mounting or side–by–side mounting of 2 units in a 1U rack space with the recommended rack adapter.
| Feature | Details |
|---|---|
| Inputs | 1 HDMI (female connector) |
| Outputs | 4 HDMI (female connectors), 1 HDMI Loop (female connector) |
| Ports | 1 Ethernet (RJ-45), 1 RS-232 (3-pin terminal block), 1 USB (Type-A connector) |
| Max Input Resolution | 4K@60Hz (4:4:4) |
| Max Input Data Rate | 18Gbps |
| Output Resolution | 1080p |
| Content Protection | HDCP 2.2 (Input/Loop Output), HDCP 1.4 (Main Outputs) |
| User Interface | Indicators: I/O detection and power LEDs, Controls: DIP-switches, computer app, firmware upgrade |
| Accessories | Power adapter, bracket set, rubber feet included |
| Power Source | 5V DC, 2.9A consumption |
| Environmental Conditions | Operating: 0 to +45°C, Storage: –20 to +70°C, Humidity: 10% to 90%, non-condensing |
| Product Dimensions | 19.00cm x 19.50cm x 2.70cm (7.48" x 7.68" x 1.06") W, D, H |
| Product Weight | 0.9kg (1.9lbs) approx. |
| Shipping Dimensions | 35.10cm x 21.20cm x 7.20cm (13.82" x 8.35" x 2.83") W, D, H |
| Shipping Weight | 1.4kg (3.1lbs) approx. |
