General |
Type: Server |
|
Hot-Swap Bays: 8 |
|
Scalability: 2-way |
|
Form Factor: Rack-mountable - 1U |
|
Security: TPM 2.0 Security Chip |
|
Localisation: Region: EMEA |
|
Built-in Devices: 6 x fans |
Expansion / Connectivity |
Bays: 8 (total) / 8 (free) x hot-swap 2.5" |
|
Interfaces: |
|
- 4 x USB 3.1 Gen 1 (1 front, 3 rear) |
|
- 1 x USB 2.0 (1 in front) |
|
- 2 x VGA (1 front, 1 rear) |
|
- 1 x management |
|
- 1 x diagnostics |
|
- 1 x USB 3.1 Gen 1 (1 internal) |
|
Slots: |
|
- 1 x PCIe 4.0 x16 / OCP 3.0 |
|
- 2 x PCIe 4.0 x16 (low-profile) |
Manufacturer Warranty |
Service & Support: 3 years on-site, next business day response |
RAM |
Configuration: 1 x 32 GB |
|
Rated Memory Speed: 3200 MHz |
|
Form Factor: DIMM 288-pin |
|
Technology: DDR4 SDRAM - ECC |
|
Effective Memory Speed: 2667 MHz |
|
Slots: 32 (Total) / 31 (empty) |
|
Features: Registered, Memory Mirroring, mixing of different memory modules not supported |
|
Max Memory: 8 TB |
Networking |
Remote Management Controller: XClarity Controller (XCC) Enterprise |
Miscellaneous |
Theft/Intrusion Protection: Chassis intrusion switch |
|
Compliant Standards: Various (BSMI, FCC, VCCI, UL, etc.) |
Power |
Installed Quantity: 1 |
|
Max Supported Quantity: 2 |
|
Power Redundancy: Optional |
|
Device Type: Power supply - hot-plug |
|
Power Provided: 1100 Watt |
|
Redundancy Scheme: 1+1 (with optional power supply) |
|
80 PLUS Certification: 80 PLUS Titanium |
|
Voltage Required: AC 100-240 V (50/60 Hz) |
Storage Controller |
Channel Quantity: 8 |
|
Buffer Size: 2 GB |
|
RAID Levels: 0, 1, 5, 6, 10, 50, JBOD, 60 |
|
Interface Type: SATA 6Gb/s / SAS 12Gb/s |
|
Type: 1 x RAID - PCIe 3.0 x8 |
|
Storage Controller Name: ThinkSystem RAID 930-8i |
Cache Memory |
Cache Per Processor: 12 MB |
|
Installed Size: L3 Cache - 12 MB |
Optical Storage |
Type: No optical drive |
Operating System |
OS Provided: No operating system |
Graphics Controller |
Video Memory: 16 MB |
|
Video Interfaces: VGA |
|
Graphics Processor: Matrox G200 |
Hard Drive |
Type: No HDD |
Dimensions & Weight |
Width: 44 cm |
|
Height: 4.3 cm |
|
Weight: 20.8 kg |
|
Depth: 77.3 cm |
Processor / Chipset |
CPU Quantity: 1 |
|
Max CPU Quantity: 2 |
|
Clock Speed: 2.8 GHz |
|
Max Turbo Speed: 3.6 GHz |
|
Number of Cores: 8-core |
|
Chipset Type: Intel C621A |
|
CPU: Intel Xeon Silver 4309Y |
Sustainability Information |
ENERGY STAR Version: 3.0 |
|
ENERGY STAR Certified: Yes |
|
EPEAT Compliant: EPEAT Bronze |
