Overview
Lenovo created the first monitor specifically designed to stow a Tiny 1L PC. This Tiny-in-One solution offer an innovative alternative to other desktop and all-in-one devices. With the introduction of the fourth generation of TIO, one that includes 22- and 24-inch options, we offer all those benefits plus many new features that greatly enhance the user experience.
Paired with the enterprise-level power and performance of Tiny desktop, the TIO Gen 4 delivers a superior computing experience that now includes an optional 10-point multi-touch screen, extended lift height, and an IR webcam with integrated mic and speakers. The addition of ThinkShutter enhances the ThinkShield security solutions built into the Tiny inside.
Modular convenience
The ThinkCentre TIO22 Gen 4 makes it easy to create your own modular all-in-one (AIO)—simply plug a compatible ThinkCentre Tiny, Nano, or similar PC (not supplied) into the back of monitor. It instantly becomes a self-contained, fully functional AIO. But unlike other AIOs, the monitor and CPU refresh separately, making upgrades efficient and easy. The TIO is compatible with most ThinkCentre Tiny or Nano PCs*, so you can have the right all-in-one for your business now.
Purposeful design
This TIO’s 21.5" FHD display is sleek and borderless and the unit takes up less space than previous generations. Its back cover has been redesigned for optimal heat dissipation and PC performance, and the stand includes a handy storage slot for your smartphone. The display also offers optional 10-point multitouch. It can also be used as a second display for your laptop, via DisplayPort.
Connect and collaborate
Thanks to the two 2W speakers and 720p rotatable camera and microphone, video calls are seamless and crystal-clear. The camera also features ThinkShutter, a privacy cover for when you’re not videoconferencing. Additionally, the TIO22 Gen 4 has plenty of ports, all conveniently situated for you to recharge and connect your other devices.
Ease & comfort of use
The TIO22 Gen 4 has been independently tested and certified by TÜV Rheinland to be eye-friendly. It also has an antiglare filter to help make your viewing more comfortable. Its redesigned stand has an additional 40mm of vertical lift, allowing for better ergonomics and more range in meeting your eye level. It also swivels 45 degrees in either direction, while the display tilts from -5 to 30 degrees and even rotates up to 90 degrees clockwise.
| Tech Specs | Specifications |
|---|---|
| PERFORMANCE | |
| Display Size | 21.5" |
| View Area | 476.1 x 267.8 mm (18.74 x 10.54 inches) |
| Panel | In-Plane Switching |
| Aspect Ratio | 16:9 |
| Resolution | 1920x1080 |
| Pixel Pitch | 0.24795 x 0.24795 mm |
| Dot / Pixel Per Inch | 102.4 dpi |
| View Angle (H / V) | 178 / 178 |
| Response Time | 4 ms (Extreme mode) / 6 ms (Typical mode) / 14 ms (Off mode) |
| Color Support | 16.7 Million |
| Refresh Rate | 60 Hz |
| Brightness | 250 nits |
| Contrast Ratio | 1000:1 |
| Color Gamut | 72% |
| Anti-glare | Yes |
| Camera | 720p camera with Think Shutter |
| Microphone | Dual microphones |
| Speakers | 2x 2W, Stereo speakers |
| Power Consumption (Typical / Maximum) | 14W / 25W |
| Power Adapter | 90W 88% Adapter |
| Display Ram / Storage / Card Slot | None / None / None |
| DESIGN | |
| Stand | Tilt, Swivel, Pivot, Height Adjust Stand |
| Color | Black |
| Side Bezel Width | 2 mm |
| Dimensions with Stand (HxWxD) | 489x220.4x568.2 mm / 19.25x8.68x22.37 inches |
| Weight (Including Stand) | 6.58 kg / 4.51 lbs. |
| Touchscreen | Advanced In-cell Touch (AIT), supports 10-point touch (for model 11GTPAT1 and 11GTPAR1 only) |
| Buttons | • Power button<br>• Exit button<br>• Menu button<br>• Mode-switching button<br>• Brightness button |
| Mounting | Supports VESA mount 100mm |
| Compatible Tiny | P340 / P330 / P320 / M90q / M80q / M70q / M75q / M920(x) / M720 / M910(x) / M710 / M715 / M900(x) / M700 / M630e / M625 / M600 Tiny / M90n / M75n Nano (with TIO kit) |
| Tiny Support / CPU / Platform | Yes / None / None |
| CONNECTIVITY | |
| Rear Ports | • 1x USB upstream port<br>• 1x DisplayPort™<br>• 1x power connector |
| Left Ports | • 1x USB 3.1 Gen 1 (on TIO)<br>• Side ports offered by installed Tiny (on Tiny) |
| Video Connector | 1x DP 1.2 |
| USB Port | USB 3.1 Gen 1 Type-A (only available when a Tiny is installed or a PC is connected) |
| Ethernet / Bluetooth® / Wireless | None / None / None |
| SECURITY & PRIVACY | |
| Physical Locks | Kensington® Security Slot™, 3 x 7 mm |
| SERVICE | |
| Base Warranty | 3-year |
| CERTIFICATIONS | |
| Environmental Certification | Energy Star Certified, TCO 8.0, TCO Edge 2.0, EPEAT™ Silver, RoHS |
| Ergonomic Certification | TÜV Rheinland® Low Blue Light, TÜV Rheinland Flicker Free, TÜV Rheinland Eye Comfort |
| Green Certifications | • EPEAT Silver<br>• ENERGY STAR® 8.0<br>• ErP Lot 5<br>• GREENGUARD®<br>• TCO Certified 8.0<br>• TCO edge 2.0<br>• RoHS compliant<br>• WEEE |
| Other Certifications | TÜV Rheinland Eye Comfort Certification |
| SOFTWARE | |
| Operating System Support | Support Windows® 7, Windows 10 |
