A Standard Smart Hotel TV with Pro:Centric Solution

Pro:Centric Cloud
Pro:Centric Cloud improves the usability of enterprise's CMS solution and cloudification of system, reinforcing the service of 3rd party solution. It also offers various design templates, improving data collection and analytics platform with an eye-catching dashboard.

Pro:Centric Direct
The hotel content management solution Pro:Centric Direct offers easy and simple editing tools, making it easy to perform service and IP network-based remote management. The Pro:Centric Direct solution enables users to edit their interface easily by providing customized interface and efficiently manages all TVs in the room. The latest PCD version provides IoT-based in-room control as well as voice control function through LG Natural Language Processing (NLP). These IoT and voice-related functions will be your starting point to prepare for the hotel rooms of next generation through artificial intelligence.

Pro:Idiom
Digital Rights Management (DRM) technology provides access to premium content to help assure rapid and broad deployment of HDTV and other high-value digital content.

Instant On
The high speed loading system enables users to enjoy content immediately after turning on the TV.

EzManager
EzManager provides a convenient installation function for automatically set up Pro:Centric TV settings without the extra effort of configuration. Auto-installation requires 1-3 minutes while manual installation requires 3-5 minutes.

DESIGN
Tool Name	MT48
Stand Type	1 pole (Fixed)
Front color	Ceramic BK
DISPLAY
Inch	24"
Resolution	1366 x 768 (HD)
Backlight Unit Type	Edge
Brightness	250 typ
Dynamic Contrast Ratio (Dynamic MCI)	1000000:1
Static (Panel) Contrast Ratio	3,000:1
Response Time (G to G, ms)	20ms max
Refresh Rate	60(50)Hz
Life span (hrs)	30,000
VIDEO
SoC	K8LpSoC (Marketing Name)
HDR_HDR 10 Pro	Yes
HDR_HLG	Yes
Game Optimizer	Yes
AUDIO
Speaker (sound output)	5W + 5W
Speaker System	2.0 ch
AI Sound	Yes
AI Acoustic Tuning	Yes (Ready)
LG Sound Sync	Yes (Required Bluetooth)
BROADCASTING SYSTEM
Digital (Terrestrial, Cable, Satellite)	DVB-T2/C/S2
Analog (NTSC / SECAM / PAL)	SECAM / PAL
Teletext (Auto Teletext)	Yes / Yes
HOSPITALITY SOLUTION
Pro:Centric Smart	Yes (Smart)
Data Streaming (IP & RF)	Yes
HCAP (GEM/HTML)	※ Service Carousel (TLL/XML)
IP Return path	Yes
Multicast / Unicast ready	Yes / Yes
webRTC (Real Time Communication)	Yes
Pro:Centric Cloud (version)	Yes (1.0)
Pro:Centric Direct (version)	Yes (5.0)
Pro:Centric Application (version)	Yes (PCA3.8)
PCS500R	Yes
PCS400R	Yes
Quick Menu (Version)	Yes (5.0)
Pro:Idiom (S/W Type)	Yes
Pro:Idiom (Mobile, Lite)	Yes
webOS version	Yes (webOS22)
Smart Home (Launcher Bar)	Yes
Gallery Mode	Yes
Quick Access	Yes
Web Browser	Yes
Pre-loaded App	Yes
SDP Server compatibility	Yes
Magic Remote Compatibility	Yes (Ready, MR18HA)
SW Clock (World Clock / Alarm)	Yes
Mood Display	Yes
Soft AP	Yes
WiFi (version)	Yes (802.11ac)
HDMI-ARC	Yes (HDMI #2)
Voice Recognition (Standalone/Solution)	Yes
OTHER FEATURE
EzManager	Yes
USB Cloning	Yes
Wake on RF	Yes
WOL	Yes / No
SNMP	Yes
Diagnostics	Yes (IP Remote)
SI Compatible Protocol	Yes (TV Link tuner, RS232C)
HTNG-CEC	Yes (1.4)
Simplink(HDMI-CEC)	Yes (1.4)
IR Out	Yes (RS-232C, HDMI)
Multi IR Code	Yes
Hotel Mode / PDM / Installer Menu	Yes (Hotel Mode)
Lock mode	Yes (Limited)
Instant ON	Yes
RJP (remote jack pack) Compatibility	●
LG/Teleadapt (RS232C), Teleadapt/Guestlink (HDMI CEC)	Yes
Mobile Remote	Yes
Moving Picture Playback (SD/HD/Plus HD)	Yes
Auto Off / Sleep Timer	Yes / Yes
Energy Saving mode	Yes
Motion Eye Care	Yes
Conformal Coating	Yes
VERTICAL FUNCTION
Healthcare Headphone Mode	Yes
Hybrid Caption (Closed Caption Digital Only)	Yes
NTP sync timer	Yes (Clock Setup)
BEACON	Yes
Video Tag	Yes (2 Supported)
JACK INTERFACE
HDMI In	1 (2.0)
USB	1 (2.0)
CI Slot	1 (CI+ 1.4 ECP)
HDMI In (HDMI Ver.)	1 (2.1)
RF In	2
AV In	1 (Phone Jack Type)
Digital Audio Out (Optical)	1
RS-232C(D-Sub 9pin / Phone jack)	1 (D-Sub 9pin, Control & Service)
External Speaker Out(3.5mm phone jack)
Audio Line Out(3.5mm phoone jack)	2 (Spk-out 1(Stereo, Max 2W with 8Ω), Vol. Control 1)
RJ45 (Usage Purpose)	2 (Ethernet, Aux)
ETC
VESA Compatible	Yes
75x75
Kensington Lock	Yes
MECHANIC
Weight without Stand	3.5
Weight with Stand	3.7
Weight in Shipping	5 / 5(W/S)
Size without Stand	556 x 344 x 54
Size with Stand	556 x 385 x 141
POWER
Power Supply (Voltage, Hz)	AC 100~240V, 50/60Hz
Power Consumption(Max)	43.7W
Power Consumption(Typ)	30.1W
Standby Power Consumption	0.5 W
REQUIRED LISTING(CERTIFICATION)
Safety	CB , CU
TREMC	CE
ErP Class	N/A
On Power Consumption	N/A
Luminance Ratio (%)	65%
Average Annual Consumption(kWh)	N/A
SDR Grade	ESDR On mode
HDR Grade	N/A
HDR On mode	N/A
ACCESSORY
Remote type	S-Con / MMR (Option)
Power Cable	Yes (1.5M)

Standard Warranty for LG Products
The estimated standard warranty for LG products varies.
Please refer to the below guide, which references general warranty periods beginning from the original purchase date.
Please note: the below is intended as a guide only, and T&Cs may vary depending on your model and product use.

Warranty for LG Monitors

Labour : 24 Months
Parts : 24 Months
NOTE: The manufacturer warranty period is the same for consumer and commercial usage.

Warranty Terms and Conditions:
Replacement Unit or Parts may be new or remanufactured service exchanges that are equivalent to new in performance and reliability.
The LG warranty does not cover any of the following actions:
a) Periodic check ups, maintenance and repair or replacement of parts due to normal wear and tear.
b) Cost relating to transport, removal or installation of the product.
c) Misuse, including failure to use the product for its normal purposes or incorrect installation.
d) Damage caused by Lightning, Water, Fire, Acts of God, War, Public Disturbances, incorrect mains voltage, improper or insufficient ventilation or any other cause beyond the reasonable control of LG.
The LG manufacturer warranty is only valid when accompanied by the original invoice, sales receipt or confirmation from LGE UK of the warranty period.

If the serial number is defaced, missing or illegible, the warranty with LGE UK is null and void. In this case you should contact the dealer from whom the product was purchased.
During the repair process it is possible that any stored data may be lost so it is strongly recommended that you backup any important data and media files before requesting a service. LG will not be responsible for any data corruption or loss however so caused during the repair process or failure of the customer to ensure that all data is properly backed up.

LG 24LN661H 24" Pro:Centric Smart Hotel TV
