| Connector A | USB 4 Type C Male | Connector B | USB 4 Type C Male |
| Housing Material | TPE | Connector Plating | Nickel |
| Pin Construction | Copper | Pin Plating | Gold |
| Dimensions | 30x12.4x6.5mm (1.18x0.49x0.26in) | Cable Length | 0.8m (2.62ft) |
| Standard | USB 4 Gen 3x2 | Colour | Black |
| Type | Round | Jacket Diameter | 4.8mm (0.19in) |
| Jacket Material | TPE | Conductor Material | Silver plated copper |
| Conductor Gauge Power | 23AWG | Conductor Gauge Data | 30AWG/33AWG/34AWG |
| Shielding | Tinned Copper Braid 85% | Supported Bandwidth | 40Gbps |
| Maximum Resolution | 8K@30Hz | Nominal Attenuation | 0.5Mhz-15Ghz ≤ 11dB |
| Minimum Bend Radius | 28.8mm (1.13in) | Operating Temperature | -20°C - 40°C (-4°F - 104°F) |
| Storage Temperature | -40°C - 80°C (-40°F - 176°F) | Packaging Type | Polybag |
| Warranty | 2 Years | Certificated | RoHS, REACH, California Proposition, UL |
| Purchasing No. | 36947 | EAN | 4002888369473 |
| Description | Downloads |
|---|---|
| Product Safety Information | Downloads |
