Lindy 10m USB 3.0 Active Extension | 43156
SKU: 43156
£35.71 (Excl. VAT)
- Description
- Specifications
- Downloads
-
High-Speed 10m USB 3.0 Extension for AV & IT Use
The Lindy USB 3.0 Active Extension Cable uses built-in active electronics to extend the cable length of a USB 3.0 device by an additional 10m whilst continuing to support data transfer rates of up to 5Gbps.
With its USB A male and USB A female connector it allows Type A devices such as storage devices, webcams and other Type A devices to be connected at longer distances to PCs, laptops and tablets, while also ensuring flexible positioning. Up to 2 extension cables can be chained together to achieve a distance of 20m.
The Lindy USB 3.0 Active Extension Cable is compatible with all USB Type A equipped computers. With plug and play functionality, this extension cable can be installed quickly and with minimum fuss, ideal for both professional and first time users.
The USB active extension cable also features a DC socket for connecting an external power supply (not included) when using USB peripherals which have higher power requirements.
Information about USB 3.0, 3.1 & 3.2
USB 3.0, USB 3.1 and USB 3.2 PCs, cables and devices are all compatible with each other, when using either a USB Type A or USB Type C host interface.
USB 3.0, USB 3.1 Gen 1 and USB 3.2 Gen 1 all support data transfer rates up to 5 Gbps.
USB 3.1 Gen 2 and USB 3.2 Gen 2 both support data transfer rates up to 10 Gbps. -
Connector A USB Type A Male Connector B USB Type A Female Power 3.5/1.35mm DC Connector Housing Material Plastic Connector Plating Nickel Pin Construction Copper Pin Plating Golden Dimensions USB A Male 16x37x9.8mm (0.63x1.46x0.39in) Dimensions USB A Female 32x85x10mm (1.26x3.35x0.39in) Length 10m (32.81ft) Standard USB 3.1 Gen 1 / 3.0 Colour Black Type Round Jacket Diameter 6mm (0.24in) Jacket Material PVC Conductor Material Tinned Copper Conductor Gauge 28/28/22AWG Shielding 85% Aluminium magnesium braid Supported Bandwidth 5 Gbps Included Hubs 2x USB 3.0 Nominal Attenuation 100MHz -1.5dB; 1.25GHz -5.0dB; 2.5GHz -7.5dB; 7.5GHz -25dB Minimum Bend Radius 60mm (2.36in) Operating Temperature 0°C - 55°C (32°F - 131°F) Storage Temperature -20°C - 70°C (-4°F - 185°F) Transmission Medium Twisted Pair Transmission Technology USB 3.1 Gen 1 / 3.0 Packaging Type Polybag Packaging Dimensions 324x335mm (12.76x13.19in) Net Weight 0.515kg (1.14lb) Gross Weight 0.6kg (1.32lb) Warranty 2 Years Certified CE, UKCA, FCC, RoHS & REACH Packaging Contents USB 3.0 Active Extension 10m No. 43156 EAN 4002888431569 Available Lengths 43155 - 5m; 43099 - 15m -
