Designed for highly demanding use cases the DisplayPort 1.2 & USB 2.0 KVM Extender is capable of supporting DisplayPort 1.2 resolutions up to Ultra HD 4K (7680x4320) at distances of up to 200m using a single MPO/MTP cable (OM3 12 Core Method A 1:1). Using fibre optic technology the Extender is capable of extending these Ultra HD video signals in real time without compression over long distances whilst also extending four USB 2.0 devices* such as a keyboard, mouse and USB drive. The Transmitter and Receiver units are electronically isolated from one another removing the risk of damage via ground loop.
* Please Note: Isochronous USB devices such as Webcams and Audio interfaces are not supported.
Package Contents:
Fibre Optic DisplayPort 1.2 & USB 2.0 KVM Extender (1 x Transmitter, 1 x Receiver)
2 x 5V 3A Multi-Country (EURO, UK, US & AUS) Power Supply
LINDY Manual
| Category | Feature | Details |
|---|---|---|
| DisplayPort Features | DP Version Supported | DP 1.2 |
| Maximum Resolution | Up to 3840x2160 | |
| DP Capabilities | Supports highest DP resolutions, MST | |
| DP++ Support | Not supported, conversion via active converters only | |
| Bandwidth | Up to 5.4Gbps per lane, 21.6 Gbps total | |
| Transmission Quality | Uncompressed, real-time, lossless | |
| USB 2.0 Features | Supported Devices | Supports most USB 2.0 devices except isochronous devices |
| Incompatibilities | Potential issues with isochronous webcams and audio adapters | |
| Data Transfer Rate | Up to 11 Mbyte/s total (approx. 1/4 of USB 2.0 max rate) | |
| Device Support | Supports USB hubs and other devices | |
| MPO / MTP Fibre Optic Link | Laser Class | Laser Class 1 product with 0.5mW output |
| Laser Safety | Automatic laser cut-off with retracted/broken MPO cable | |
| Optical Transmitters | Automatic shutdown when input signals are off | |
| MPO Cable Compatibility | 12-core MPO cables OM3 1:1 | |
| Technical Specifications | Dimensions (TX and RX) | Approx. 18 x 12 x 3 cm each |
| Weight (TX and RX) | Approx. 0.6kg each | |
| Total Weight | Approx. 1.7kg incl. accessories | |
| Operating Temperature | -10°C to 50°C | |
| Storage Temperature | -20°C to 75°C | |
| Usage Environment | Indoor use in well-ventilated locations | |
| Power Consumption | TX: 0.5A / 2.5W, RX: 0.8A / 4W plus connected USB devices | |
| Notifications | MPO/MTP Cable | 1:1 by Method A, up to 200m |
| Handling Cautions | Keep glass fibre plugs/sockets dust-free, avoid high tensile forces, and maintain minimum bending radius | |
| Minimum Bending Radius | Approx. 10cm |
