Bring HDMI® ARC Audio into Dante® Networks
The Lindy 2ch HDMI® ARC to Dante® Encoder provides a simple and reliable way to convert HDMI® ARC audio into Dante® network audio, making it ideal for meeting rooms, hospitality displays, education spaces and professional AV installations.
Seamless HDMI® ARC Audio Integration for Dante® Systems
Designed for modern AV environments, this compact encoder converts 2 channel HDMI® ARC audio into low latency Dante® and AES67 network audio with support for 44.1 / 48kHz sample rates at 24-bit resolution. Flexible USB-C or PoE powering, plug and play operation and multiple control options make it easy to deploy within corporate, education, hospitality and professional AV systems.
At a Glance
HDMI® ARC to Dante® conversion
Integrates HDMI® ARC audio sources into Dante® audio networks.
24-bit audio performance
Supports 44.1 / 48kHz sampling rates for clear audio reproduction.
USB-C or PoE powered
Flexible powering options simplify installation and integration.
Plug and play operation
Designed for fast and straightforward professional deployment.
Key Benefits
Integrates HDMI® ARC sources into Dante® systems
Converts HDMI® ARC audio into Dante® and AES67 network audio, allowing displays and AV devices to become part of scalable professional audio infrastructures.
Supports professional audio quality
24-bit audio with 44.1 / 48kHz sample rates ensures clear, accurate and low latency audio transmission across AV environments.
Broad compatibility with Dante® and AES67
Native AES67 RTP support improves interoperability across compatible networked audio systems and ecosystem architectures.
Flexible control and configuration
Input sensitivity and volume can be managed through CEC, a web-based GUI or API commands, offering greater control flexibility for system integrators.
Simple installation and deployment
Power can be supplied via USB-C or 802.3af PoE, reducing cabling requirements and simplifying integration within racks, meeting rooms and AV installations.
Compact professional design
The durable metal housing and compact footprint make the encoder suitable for permanent installations, mobile production and professional AV environments.
Typical Applications
The 2ch HDMI® ARC to Dante® Encoder is ideal for integrating HDMI® ARC audio from displays and AV devices into Dante® audio systems within meeting rooms, hospitality environments, lecture theatres, retail spaces and professional AV installations. It is also suitable for broadcast, streaming and networked audio deployments requiring simple and reliable HDMI® ARC audio integration.
Technical Summary
The encoder supports Dante® and AES67 protocols with 24-bit audio at 44.1 / 48kHz sample rates. It features one HDMI® ARC input, one RJ45 network output and supports transmission distances up to 100m (328.08ft) over standard Ethernet infrastructure.
Power can be supplied via USB-C or 802.3af PoE, with maximum power consumption of 1W. The compact metal enclosure measures 114 x 48 x 26mm and is designed for reliable use in fixed and portable AV installations.
The encoder is supplied with mounting ears and screws, a user manual and is backed by a 3-year warranty.
| Sample Rate | 44.1/48kHz | Bit Depth | 24-bit |
| Protocol | Dante, AES67 | Supported Bandwidth | 100Mbps |
| Maximum Distance | 100m (328.08ft) | Input | HDMI® (Female), USB-C power (Female) |
| Output | RJ45 (Female) | Dimensions WxDxH | 114x48x26mm (4.48x1.88x1.02in) |
| Housing Material | Metal | Net Weight | 0.170kg (0.37lb) |
| Operating Temperature | -5° - 55°C (23°F - 131°F) | Storage Temperature | -25°C - 70°C (-13°F - 158°F) |
| Power Requirements | 5VDC 3A / 802.3af PoE | Power Consumption | 1W (max) |
| Colour | Black | Packaging Type | Carton Box |
| Packaging Dimensions | 135 x 75 x 35 mm (5.31 x 2.95 x 0.46in) | Gross Weight | 0.210kg (0.46lb) |
| Warranty | 3 Years | Product Compliance | CE, UKCA, FCC, RoHS & REACH, CP65 |
| Package Contents | 2ch HDMI® ARC to Dante® Encoder; 2x mounting ears with screws; User Manual | No. | 70620 |
| EAN | 4002888706209 |
| Description | Downloads |
|---|---|
| User Manual | Download |
