Allows DVI-D video signals to be sent up to 30m using low cost (not included)
Supports HDTV resolutions of 480i, 576i, 480p, 576p, 720p and 1080p
HDCP not suported
Dimensions: 4 x 5 x 2.5cm (WxDxH)
2 year warranty
| Category | Details |
|---|---|
| Specifications | |
| AV Interface | DVI-D |
| Interface Standard | DVI-D 1.1 (Single Link) |
| Supported Bandwidth | 4.95 Gbps |
| Maximum Distance | 30m (98.42ft) - 1024x768@60Hz / Cat.6a |
| 20m (65.62ft) - 1680x1050@60Hz / Cat.6 | |
| 15m (49.21ft) - 1920x1200@60Hz / Cat.6a | |
| Maximum Resolution | 1920x1200@60Hz |
| HDCP Support | - |
| EDID Pass Through | - |
| Supported Audio | - |
| Separate Audio Ports | - |
| IR Support | - |
| CEC Support | - |
| Serial Interface | - |
| Transmission Protocol | - |
| Transmission Medium | 1 x Cat.6A / Cat.6 |
| Laser Class | (only for Fibre) - |
| Wavelength | (only for Fibre) - |
| Chipset | - |
| Special Features | - |
| Connectors | |
| Transmitter Input | DVI-D (Male) |
| Transmitter Output | RJ45 (Female) |
| Receiver Input | RJ45 (Female) |
| Receiver Output | DVI-D (Male) |
| Bidirectional Ports | - |
| Power | - |
| Physical Properties | |
| Dimensions (WxDxH) | 40x50x25mm (1.57x1.97x0.98in) per unit |
| Housing Material | Plastic |
| Net Weight | 0.028kg (0.06lb) per unit |
| Operating Temperature | 0°C - 55°C (32°F - 131°F) |
| Storage Temperature | -20°C - 85°C (-4°F - 185°F) |
| Humidity | 0 - 95% RH (non-condensing) |
| Power Requirements | - |
| Colour | Black |
| Description | Downloads |
|---|---|
| User Manual | Downloads |
