It’s time to supercharge your home network with the Generation 6 wireless network and our latest addition to the beloved hAP series. hAP ax² has everything you might need in a primary home access point – and more! Forget endless reviews and comparisons – this is the perfect device for 99% of homes.
Wireless signal is now stronger than ever. Here are the two main ingredients of hAP ax’s success: a state-of-the-art dual-band, dual-chain 4-4.5 dBi radio, and the 802.11ax standard with Wave2 support. Let’s compare it to the previous generation: depending on your overall setup, that means up to 40% higher speed in the 5 GHz and up to 90% higher speed in the 2.4 GHz spectrum!
Some might ask – why do we even need higher wireless speeds? Well, countless use cases have been previously impossible or difficult to pull off. For example, working with large media files over the wireless network – without the need to download and upload everything. Do you really have the time to wait? Grab a hAP ax² and save more time for the essential things in life!
The modern quad-core CPU running at 864 MHz combined with a solid GB of RAM packs a hefty punch when it comes to heavy operations like complex firewall rules, IPsec hardware encryption, using more threads or experimenting with the most advanced RouterOS features. And with the addition of WPA3 advanced encryption support, you’re safer than ever before.
Like the previous models, hAP ax² can be mounted vertically, horizontally, or even on the wall – without sacrificing the strong signal.
With so many products and features on the market, even an experienced user can become confused. So it’s time for a simple truth for a simple choice: you can’t go wrong with a hAP ax² in most homes.
| Antenna | Antenna gain level (max) | Antenna gain level (max) | 4 dBi |
| Compliance certificates | RoHS | LED indicators | Yes |
| Product colour | Black | Product type | Tabletop router |
| Built-in processor | Yes | Certification | CE, FCC, IC, EAC |
| Flash memory | 128 MB | Internal memory | 1000 MB |
| MTBF | 100000 h | Operating system | RouterOS |
| Processor cores | 4 | Processor frequency | 864 MHz |
| Country of Origin | Lithuania | Tariff No. | 8517620000 |
| UNSPSC Code | 43222609 | Reset button | Yes |
| Cabling technology | 10/100/1000Base-T(X) | Ethernet LAN | Yes |
| LAN data rates | 10, 100, 1000 | LAN interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.11a/b/g/n/ac/ax | Operating temp | -40 - 50 °C |
| Package Depth | 22 cm | Package Weight | 0.55 kg |
| Package Height | 51 cm | Package Width | 25 cm |
| AC adapter included | Yes | Screws included | Yes |
| DC-in jack | Yes | RJ-45 ports | 5 |
| External power adapter | Yes | Output current | 0.6 A |
| Output voltage | 12 - 28 V | Power consumption | 12 W |
| Power over Ethernet | Yes | Power source type | DC, PoE |
| Net Weight | 0.51 kg | Product Depth | 10.1 cm |
| Product Height | 3.7 cm | Product Width | 12 cm |
| Sustainability certificates | RoHS | Brand Name | MikroTik |
| Warranty | 15 Month(s) | Ethernet WAN | Yes |
| WAN connection type | RJ-45 | Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi band | Dual-band (2.4 / 5 GHz) | Wi-Fi standards | a/b/g/n/ac/ax |
| WLAN rate (1st) | 574 Mbit/s | WLAN rate (2nd) | 1200 Mbit/s |
| WLAN rate (max) | 1200 Mbit/s | Main category | Network |
| Subcategory | Wireless Network | Subcategory | Wireless Routers |
| Description | Downloads |
|---|---|
| MikroTik hAP ax² Wi-Fi 6 Dual-Band Gigabit Router | C52IG-5HAXD2HAXD-TC DataSheet | Download |
| MikroTik hAP ax² Wi-Fi 6 Dual-Band Gigabit Router | C52IG-5HAXD2HAXD-TC User Manual | Download |
| MikroTik hAP ax² Wi-Fi 6 Dual-Band Gigabit Router | C52IG-5HAXD2HAXD-TC Quick Guide | Download |
