Meticulously powerful signage
When true-to-life colour rendition is essential, the MA Series’ advanced feature set delivers calibrated precision, without compromise. For specialist applications, the wide colour gamut panel, SpectraView engine technology and 8K signal processing, positions the MA series at the high end of professional content delivery.
The MA series’ modular design includes Intel® Smart Display Module (Intel® SDM) technology integrated into the display, facilitating powerful media playback for the most intuitive signage creation and delivery. Featuring an integral audio amplifier, multi-picture mode technology and extensive connectivity including video out, the MA series offers versatile functionality for corporate signage and prestige retail applications.
Benefits
Unhindered readability – no reflections from windows or other light sources means no disruption to the visibility of signage content or meeting room presentation
Wide colour gamut – high-performance panel technology delivers a wider spectrum of colours for a superb visual experience
Safe for public environments – a metal back cover and intelligent heat management ensure safe use in public spaces where fire-retardancy is mandatory
Enhanced imaging performance – advanced settings of all relevant visual parameters allow full control of brightness, colour, gamma and uniformity via the SpectraView Engine for precise, natural images.
Mission-critical 24/7 ready operation – the meticulous selection of industrial-grade components and careful design focused on demanding usage scenarios accompany an impressive and continuous viewer experience.
| Specification | Value |
|---|---|
| Panel Technology | IPS with Edge LED backlights |
| Screen Size | 43 inches / 108 cm |
| Aspect Ratio | 16:9 |
| Brightness | 500 cd/m² |
| Contrast Ratio | ≥8000:1 |
| Viewing Angle | 178° horizontal / 178° vertical (typ. at contrast ratio 10:1) |
| Colour Depth | 1.073 billion (10bit) |
| Colour Gamut | 86% of DCI |
| Response Time (typ.) | 8 ms |
| Panel Refresh Rate | 60 Hz |
| Haze Level | Pro (28%) |
| Supported Orientation | Face Up, Landscape, Portrait |
| Native Resolution | 3840 x 2160 |
| Supported Resolutions | 1024x768, 1280x1024, 1280x720, 1360x768, 1366x768, 1400x1050, 1440x900, 1600x1200, 1920x1080, 1920x1200, 1920x2160, 2560x1440, 2560x1600, 3840x2160, 4096x2160, 7680x4320 |
| Horizontal Frequency | 15-135 kHz |
| Vertical Frequency | 23-86 Hz |
| Input Video Digital | 2 x DisplayPort (with HDCP); 2 x HDMI (with HDCP) |
| Input Audio Digital | 1 x DisplayPort; 2 x HDMI |
| Input Control | LAN 100Mbit, remote control wire (3.5mm jack), RS232 |
| Input Data | 1 x USB 2.0 (Downstream), 1 x USB 2.0 (Powered 5V/2A, Firmware Updates), 1 x USB 2.0 Type-B (Downstream) |
| Output Video Digital | 1 x DisplayPort (loop through: DisplayPort, SDM slot-in PC); 1 x HDMI (loop through: HDMI, SDM slot-in PC) |
| Output Audio Analogue | 1 x 3.5 mm jack |
| Output Control | 1 x LAN 100Mbit |
| Input Detect | Custom; First; Last |
| PiP/PbP | Dual-Split; Quad-Split; scalable picture size |
| Factory Calibration | Gamma; Intensity; RGB; Uniformity; White Point |
| Sensor Calibration (through USB) | PC-less Calibration with USB Sensor MDSVSensor3; White Copy (post self-calibration) |
| Calibration with Software | Corner Uniformity; Gamma; Intensity; RGB; Update Factory Calibration; White Point |
| Calibration Software | NEC Display Wall Calibrator |
| Intel® SDM | accepts Intel® Smart Display Modules Large and Small up to 66 W |
| Compute Module Slot | RPi Compute Module 4 |
| Ambient Light Sensor | Integrated, triggered actions programmable |
| Temperature Sensor | Integrated, 3 sensors, triggered actions programmable |
| Power Consumption Eco/max. | 70 W shipping |
| Power Savings Mode | <0.5 W; <2 W (Networked Standby) |
| Power Management | VESA DPMS |
| Power Supply | 100-240 V AC; 50/60 Hz; internal |
| Operating Temperature | +0 to +40°C |
| Operating Humidity | 20% to 80% |
| Storage Humidity | 10% to 90% |
| Storage Temperature | -20 to 60°C |
| Dimensions (W x H x D) | 968.2 x 561 x 67.1 mm |
| Weight | 18.5 kg |
| Bezel Width | 11 mm (left, right, and top); 15.6 mm (bottom) |
| VESA Mounting | 300 x 300 (FDMI); 4 holes; M6 |
| Ingress Protection | IP5x (front); IP2x (back) |
| Packaging Dimensions | 1120 x 700 x 203 mm |
| Packaging Weight | 23 kg |
| Colour Bezel | Pantone 426M (black) |
| Material | Metal |
In Warranty Support
Warranty Period 36 Months
Contact: NEC Display Solutions
Email uklcdservice@emea.nec.com
Manufacturers Website http://www.nec-display-solutions.co.uk
NEC deal with all your AfterCare requirements for the product you have purchased, they can help with technical queries and offer advice.
| Description | Downloads |
|---|---|
| Datasheet | Downloads |
| User Manual | Downloads |
| Product Drawings | Downloads |
| Energy Label | Downloads |
