  • Description
  • Specifications
  • Warranty
  • Enter a world of interactive white-boarding

    Upgrade your lectures and meetings with NEC’s all-in-one collaboration boards, in three different sizes, featuring UHD resolution and up to 20 touch points. Based on infrared touch technology the user experiences perfect usability with a rapid touch response. Business and educational sessions start-up instantly with built-in whiteboard and wireless screen sharing functionalities without any hidden costs. The embedded annotation tool lets you annotate over any content shown on the screen.

    For more demanding applications, the OPS slot provides the opportunity to enhance the computing power. With sizes including 65’’, 75’’ and 86’’, the NEC CB Series offers the ideal solution for your meeting and class rooms.

    All NEC CB Series displays come with three magnetic pens and a wall-mount fitting for easy installation.

    Out-of-the-box collaboration – thanks to embedded computing with built-in annotation tools and wireless presentation capabilities.
    Protective Glass – premium toughened glass protects the security of the panel yet delivers a perfect touch experience with anti-glare coating to minimise reflections and fingerprints.
    Multi-Touch – true multi-touch support with up to 20 simultaneous touch points.
    Simple operation – with easy front access to USB ports and controls for major functionalities
    Cost Saving Device Management – save effort whilst managing all connected NEC devices from a centralised location by using the NaViSet Administrator 2 software tool.

  • Parameter Value
    Panel Technology IPS with Direct LED backlights
    Active Screen Area (W x H) 1,428.5 x 803.5 mm
    Screen Size 65 inch / 163.9 cm
    Aspect Ratio 16:9
    Pixel Pitch 0.372 mm
    Brightness 350 cd/m² (300 cd/m² in shipment setting)
    Contrast Ratio 1200:1
    Viewing Angle 178° horizontal / 178° vertical (at contrast ratio > 10:1)
    Colour Depth 1.073 billion (10-bit)
    Response Time 8 ms (grey-to-grey)
    Haze Level 3%
    Supported Orientation Landscape
    Touch Technology Infrared
    Number of Touches Real multi-touch up to 20 touches
    Touch Method Finger, Gloves, Stylus (≥ 8 mm)
    Supported Operating System Native Multi-Touch: Windows 7, 8, 10, Linux, Android; Default Mouse: Windows XP, Vista, Mac OS X
    Data Interface USB-HID
    Accuracy < 2 mm
    Palm Rejection No
    Windows Ink No
    Glass Type Thermal-tempered with anti-glare coating
    Glass Thickness 4 mm
    Light Transmission 88% (+/- 1%)
    Reflection Rate 4%
    Glass Hardness 7H
    Native Resolution 3840 x 2160
    Supported Resolutions 1920 x 1080, 3840 x 2160, 4096 x 2016
    Supported Resolutions (HDMI) 3840 x 2160 (60 Hz), 4096 x 2016 (24 Hz)
    Horizontal Frequency 26 - 135 kHz
    Vertical Frequency 23 - 86 Hz
    Input Video Analogue 1 x VGA
    Input Video Digital 3 x HDMI
    Input Audio Analogue 1 x 3.5 mm jack
    Input Audio Digital 3 x HDMI
    Input Control LAN 100Mbit, RS232
    Input Data 2 x USB Type-B (Upstream), 6 x USB 2.0 (Downstream)
    Output Audio Analogue 1 x 3.5 mm jack
    Output Audio Digital 1 x SPDIF
    Output Control 1 x LAN 100Mbit
    OPS Slot Open pluggable specification (NEC / Intel OPS standard)
    OPS Max. Current / Power 3.5 A / 63 W
    Power Consumption Eco: 165 W (shipment setting), Max: 400 W
    Power Savings Mode < 0.5 W, < 2 W (Networked Standby)
    Operating Temperature +0 to +40 °C
    Operating Humidity 10 to 90%
    Dimensions (W x H x D) Without stand: 1,488.4 x 896.8 x 87.5 mm
    Weight Without stand: 39.2 kg
    Bezel Width 17.7 mm (left, right, and top), 45.7 mm (bottom)
    VESA Mounting 4 holes; 600 x 400 (FDMI); M8
    Built-in Applications File Manager, Input Select, Setting, Web Browser, Whiteboard - Mosaic Canvas, Wireless Presentation - Mosaic Connect
    System Memory 2 GB RAM
    Internal Storage 16 GB ROM
    Accessories Soundbar, Trolley, Wall mount, Wireless LAN module
    Special Characteristics AMX NetLinx Support, HDMI with UHD at 60 Hz, NaViSet Administrator 2, Scheduler
    Colour Versions Black Front Bezel, Black Back Cabinet
    Safety and Ergonomics BSMI, CE, EAC, EMC Class B, FCC, PSB, RCM, REACH, RoHS, SASO, UL/C-UL
    Audio Integrated Speakers (2 x 12 W)
    Shipping Content 3 x Stylus, HDMI Cable, Power Cable, Remote Control, USB cable, User Manual, VGA cable, Wall Mount
    Warranty 3 years warranty incl. backlight
    Operating Hours 12/7
  • In Warranty Support
    Warranty Period 36 Months
    Contact: NEC Display Solutions
    Tel. No. 01952 237003
    Email uklcdservice@emea.nec.com
    Manufacturers Website http://www.nec-display-solutions.co.uk

    NEC deal with all your AfterCare requirements for the product you have purchased, they can help with technical queries and offer advice.


    Please contact them direct.
    You will need the following information to hand:

    * Customer Name
    * Email Address
    * Product Model Number
    *Proof of Purchase
    * Serial Number
    * Details of the fault
    * Any permanent security markings?
    * Any physical damage?
    * Any non-NEC repair or modi?caon?

    Once provided NEC will be able to issue a return and provide a replacement if required.

    If you have any questions or would like further advise, please feel free to contact our AfterCare Team (ACE) on 02081 919223 / who will be happy to assist

    3 Year On-Site Warranty. Please contact NEC for full Ts & Cs (exclusions apply).
