M4300-52G-PoE+ (GSM4352PA)
48x1G PoE+ 480W, 2x10G, 2xSFP+ Managed Switch
Full-Width 48x1G PoE+ Stackable Managed Switch with 2x10GBASE-T and 2xSFP+ (550W PSU) (GSM4352PA)
Business Continuity Management
Full-width switches offer dual redundant, modular power supplies (select m4300 models)
High Availability (HA)
Non-stop forwarding (NSF) virtual chassis architectures with hitless failover across the stack
Multi-Resiliency
Stacking and distributed link aggregation allow for zero downtime and load balancing capabilities
PVST+ Interoperability
Per VLAN Spanning Tree and Per VLAN Rapid Spanning Tree (PVSTP/PVRSTP)
Link Dependency
Enables or disables ports based on link state of different ports
Advanced IPv4/IPv6 security
Malicious code detection, DHCP Snooping, IP Source Guard protection and DoS attacks mitigation
Fiber Ports
48 SFP+ Fiber ports have 1G/10G speeds & 2x 10Gb Copper
Simple GUI
Full- functional Web console (GUI) for IT admins who prefer an intuitive graphical interface
Flexible & Efficient
Line-rate Spine and Leaf topologies offer many possibilities for server rooms, branch collapsed cores, or at the edge of growing networks
Mix & Match Stacking
Stack between 10/40 Gigabit and 1 Gigabit models using any 10G/40G port, with any media type (RJ45, SFP+, DAC cables). Vertical, horizontal, manage as one unit
Room to Grow
With PoE+, plug and play ports, and hot swap, you're ready to grow whenever you need to
Industry Standard
SNMP, RMON, MIB, LLDP, AAA, sFlow, RSPAN and PTPv2 1-step transparent clock implementation (select M4300 models)
Zero Touch AV-over-IP
Pre-configured for Out-of-Box L2 Multicast (SDVoE-ready)
No Delay
Non-Blocking Fabric for Near-Zero Switch Latency
NETGEAR IGMP Plus™
Prevent network flooding with effortless multicast implementation of Layer 2 Multicast
Dedicated Design
ProAV Engineering Services for AV Network Design and Install Support ProAVDesign@NETGEAR.com
| Feature | Description |
|---|---|
| Warranty | NETGEAR ProSAFE® Limited Lifetime Hardware Warranty |
| Next Business Day Hardware Replacement | Coverage, availability, and terms and conditions |
| Support | ProSUPPORT 24x7 Advanced Technical Support via phone for 90 days (remote diagnostics). Extendable with 1, 3, or 5-year contracts. Lifetime 24x7 Advanced Technical Support via chat. |
| Hardware Specifications | 48x1G PoE+ Stackable Managed Switch with 2x10GBASE-T and 2xSFP+ (550W PSU) |
| Ordering Number | GSM4352PA |
| Acoustics | 39.8 dB @ 25°C (77°F) |
| Power Consumption (Max) | 865 Watts |
| 1G RJ45 Ports | 48 x 10/100/1000 |
| 10G RJ45 Ports | 2 x 10GBASE-T (Fast Ethernet, 1G, 10G) |
| 10G Fiber SFP+ Ports | 2 x SFP+ (1G and 10G speeds) |
| Power over Ethernet | 48 x PoE+ (30W per port) |
| PoE Budget | 480W with 1 PSU 480W with 2 PSUs in RPS mode 720W with 2 PSUs in EPS mode |
| External Power Redundancy | RPS4000v2 for redundancy (RPS) when 2 internal PSUs are used in EPS mode |
| Feature Set | Layer 3 (static, policy-based, RIP, OSPF, VRRP, PIM dynamic routing) |
| Management Ports | 1G Ethernet OOB service port (RJ45) RS232 serial RJ45 (console) Mini-USB console USB for storage, logs, config, or image files |
| Form Factor | Full width with dual, redundant modular PSUs |
| Description | Downloads |
|---|---|
| Netgear GSM4352PA-100NES 48x1G PoE+ 480W, 2x10G, 2xSFP+ Managed Switch Datasheet | Downloads |
