Each port delivers up to 2000Mbps of network speed (full duplex)
Fast, auto-switching and auto-sensing 10/100/1000Mbps Ethernet connection
16 switched ports provide bandwidth for PCs, servers or switches
Auto Uplink™ automatically adjusts for straight-through or crossover cables
Plug and play—begins working as soon as it is powered on
Integrates 10-,100- and 1000Mbps devices into your network
Compact size for desktop or for mounting in a standard 19-inch rack
16 ports deliver up to 2000Mbps of dedicated, non-blocking bandwidth per port
Instant Plug-N-Play connectivity with Auto-negotiation and Auto MDI/MDI-X
Easily combine new or existing 10-, 100- and 1000Mbps devices within your network
802.1p QoS support for prioritizing voice and video in the network
Jumbo Frame Support up to 9KB
| Specification | Value |
|---|---|
| Speed | 10/100/1000Mbps Gigabit Ethernet |
| Number of Ports | 16 |
| PoE ports | n/a |
| Total PoE Budget | n/a |
| Loop Detection | n/a |
| Short Cable Power Saving | n/a |
| Energy Efficient Ethernet Support | Yes (IEEE 802.3az) |
| Jumbo Frame Support | 9KB |
| Queue WRR Ratio | 1:2:4:8 |
| MAC Table Size | 8K |
| Packet Buffer Size | 256KB |
| IEEE 802.1p QoS | Yes |
| Max Power Consumption | 11.8W |
| Operating Temperature | 0 to 50°C |
| MTBF (hours) | 441,123 |
| FCC Class | A |
| Description | Downloads |
|---|---|
| Netgear JGS516-200EUS 16-Port Gigabit Ethernet Unmanaged Switch Datasheet | Downloads |
