Novastar CX40 Pro LED Display Controller
SKU: CX40PRO
£7,291.85 (Excl. VAT)
- Description
- Specifications
-
Novastar CX40 Pro LED Display Controller
The CX40 Pro is a 4K LED display controller by Novastar. A 5.5-inch LCD touchscreen, a control knob and a back button on the device make it easy to control when you don’t want to use the comprehensive, user-friendly VMP software. Cascading control via Ethernet is possible too. The CX40 Pro offers a range of inputs and outputs for ultimate flexibility. Inputs include two HDMI 2.0 + loop, one DP 1.2 and two 12G-SDI + loop, while the outputs consist of six 5GB Ethernet ports and one 40G optical port. There are also two network ports, one auxiliary port, an S/PDIF optical out and a Genlock input and loop on board. Advanced features include three independent layers, image scaling, colour replacement, 14Ch colour correction, low latency support and display system monitoring. Note that the CX40 Pro uses a new type of receiver card (CA50E/CA50C/XA50) and is, therefore, not backwards compatible.
-
Category Specification Inputs DP 1.2 (1), HDMI 2.0 (2), 12G-SDI (2) Outputs Main Outputs (6), HDMI 2.0 Loop (2), 12G-SDI Loop (2), S/PDIF (Out) (1) Ethernet Speed (LED Screen) 5 Gbit/s Optical SFP Slot Type: 40G, SFP Slot Quantity: 1 Software Specifications Control Software: VMP Extra Features Scaling Function: Yes, Layers: 3, GenLock: In & Out Control and Programming Display: Touch, Display Size: 5.5" Maximum Loading Capacity 9 Mpx Maximum Input Resolution 4096 x 2160 Control Options Ethernet Electrical Specifications Power Supply: 100-240 V AC 50/60 Hz, Power Consumption: 105 W Power Connector In IEC Data Connector In RJ45 Data Connector Out etherCON, RJ45 Mechanical Specifications Width (w/ handles): 483 mm (19.016″), Width (w/o handles): 446 mm (17.559″) Height (w/ handles): 881 mm (34.685″) Depth (w/ handles): 472 mm (18.583″), Depth (w/o handles): 424 mm (16.693″) Weight 8.1 kg (17.857 lb) IP Rating IP20 (indoor use only) Colour Black Thermal Specifications Max Temp: 45°C (113°F), Min Temp: -10°C (14°F) Operating Humidity 0-80 % RH Included Items CAT-5 Cable, DP-DP Cable, HDMI-HDMI Cable, IEC Cable
