NovaStar Independent Controller | MCTRL600
SKU: MCTRL600
£267.45 (Excl. VAT)
- Description
- Specifications
-
NovaStar Independent Controller
MCTRL600 is a controller developed by NovaStar with a single-unit loading capacity of 1920×1200@60Hz. MCTRL600 utilizes UART to cascade and control multiple units. Suitable for a variety of applications, especially rental and fixed installations such as stage broadcasts, monitoring centers, sports arenas, and more.
12bit/10bit HDMI input, DVI input
HDMI input, external signal input
HDCP Blue-Ray input
8bit video source loading capacity of 1920×1200@60Hz.
12bit video source loading capacity of 1440×900@60Hz
Support for custom resolutions: 3840 pixels of H resolution, 3840 pixels of V resolution Supports cascading for control of multiple units Support for multiple signal formats: RGB, YCrCb4:2:2, YCrCb4:4:4 Certifications, CE, RoHS, FCC, EAC, IC -
Category Specifications Electrical Parameters Input Voltage AC 100 V–240 V, 50/60 Hz Rated Power Consumption 16 W Operating Environment Temperature Range -20°C to 60°C Humidity Range 0% RH to 90% RH (non-condensing) Physical Dimensions Dimensions (W x D x H) 482 mm × 268.5 mm × 44.4 mm Weight 2.9 kg Space Requirement 1U Rack Space Certifications FCC, RoHS, EAC, IC, PFOS, LVD, EMC Video Inputs DVI Input 1 × DVI HDMI Input 1 × HDMI 1.3 Audio Input 1 × Audio Input Light Sensor Connector 1 × Light Sensor Port Video Output Max Resolution 1920 × 1200 @ 60Hz (with downward compatibility) Ethernet Outputs 4 × RJ45 Gigabit Ethernet (up to 650,000 pixels each) USB Control Port 1 × Type-B USB UART Control Ports UART IN and UART OUT for device cascading Calibration Technology Supports NovaStar calibration technology for fast and efficient performance Supported Video Formats Multiple standard video formats supported Packing Information Carrying Case 530 mm × 140 mm × 370 mm (Craft paper box with NovaStar print) Accessory Box 402 mm × 347 mm × 65 mm (Craft paper box) Included Accessories 1 × Power Cord, 1 × USB Cable, 1 × DVI Cable Packing Box 550 mm × 440 mm × 175 mm (Craft paper box with NovaStar print)
