Picture/Display |
|
Diagonal Screen Size (metric) |
81.28 cm |
Diagonal Screen Size (inch) |
32 inch |
Aspect Ratio |
16:9 |
Panel Resolution |
1920 x 1080p |
Pixel Pitch |
0.36375 (H) x 0.36375 (V) mm |
Optimum Resolution |
1920 x 1080 @ 60 Hz |
Brightness |
400 cd/m² |
Display Colours |
16.7 Million |
Contrast Ratio (Typical) |
1200:1 |
Dynamic Contrast Ratio |
500,000:1 |
Response Time (Typical) |
8 ms |
Viewing Angle (Horizontal) |
178 degree |
Viewing Angle (Vertical) |
178 degree |
Picture Enhancement |
3/2 - 2/2 motion pull down, Motion compens. deinterlacing, Dynamic contrast enhancement, Progressive scan |
Panel Technology |
ADS |
Operating System |
Android 11 |
Haze |
25% |
Connectivity |
|
Audio Output |
3.5 mm jack |
Video Input |
DVI-I (x 1), DisplayPort 1.4 (x 1), HDMI 2.0 (x 2), USB 3.0 (x 2), VGA (via DVI) |
Audio Input |
3.5 mm jack |
Other Connections |
4G/LTE antenna connectors, Micro USB (x 1) (OTG), USB 2.0 (x 1) |
Video Output |
DisplayPort 1.4 (x 1) |
External Control |
RJ45, RS232C (in/out) 2.5 mm jack, IR (in/out) 3.5 mm jack |
Convenience |
|
Placement |
Landscape (24/7), Portrait (24/7), Tiled Matrix (Up to 10 x 15) |
Screen-saving Functions |
Pixel Shift |
Keyboard Control |
Hidden, Lockable |
Signal Loop Through |
RS232, IR Loop through, DisplayPort |
Energy-saving Functions |
Smart Power |
Network Controllable |
RS232, External 4G mPCIe slot, RJ45 |
Sound |
|
Built-in Speakers |
2 x 10 W RMS |
Power |
|
Mains Power |
100 ~ 240 VAC, 50 ~ 60 Hz |
Consumption (Typical) |
38 W |
Standby Power Consumption |
<0.5 W |
Energy Label Class |
G |
Supported Display Resolution |
|
Computer Formats |
1920 x 1080, 60 Hz, 1024 x 768, 60 Hz, 1280 x 1024, 60 Hz, 1280 x 720, 60 Hz, 1440 x 900, 60 Hz, 1600 x 900, 60 Hz, 1680 x 1050, 60 Hz, 640 x 480, 60 Hz, 800 x 600, 60 Hz |
Video Formats |
1080i, 50, 60 Hz, 576i, 50 Hz, 576p, 50 Hz, 480p, 60 Hz, 480i, 60 Hz, 1080p, 50, 60 Hz, 720p, 50,60 Hz |
Dimensions |
|
Set Width |
726.5 mm |
Set Height |
425.4 mm |
Set Depth |
65.1 mm (@Wall mount), 69.1 mm (@AC) |
Set Width (inch) |
28.60 inch |
Set Height (inch) |
16.75 inch |
Set Depth (inch) |
2.56 inch (@Wall mount), 2.72 inch (@AC) |
Bezel Width |
11.9 mm (T/L/R), 17.2 mm (B) |
Product Weight (kg) |
5.7 kg |
Product Weight (lb) |
12.57 lb |
Wall Mount |
100 (H) x 100 (V) mm / 200 (H) x 200 (V) mm, M4 |
Operating Conditions |
|
Altitude |
0 ~ 3000 m |
Temperature Range (Operation) |
0 ~ 40 °C |
MTBF |
50,000 hour(s) |
Temperature Range (Storage) |
-20 ~ 60 °C |
Humidity Range (Operation) |
20–80% RH (No condensation) |
Humidity Range (Storage) |
5–95% RH (No condensation) |
Multimedia Applications |
|
USB Playback Video |
MPEG, H.263, H.264, H.265, AVI, MP4, MPEG4, VP8, VP9, WEBM |
USB Playback Picture |
BMP, JPEG, PNG |
USB Playback Audio |
AAC, HEAAC, MPEG |
Internal Player |
|
CPU |
2 x A72 + 4 x A53 |
GPU |
ARM Mali-T860 MP4 |
Memory |
4 GB RAM |
Storage |
32 GB eMMC |
Accessories |
|
Included Accessories |
RS232 daisy-chain cable, Philips logo (x 1), USB Cover (x 1), Screws, AC Power Cord, AC Switch Cover, IR sensor cable (1.8 m) (x 1), Quick start guide, Remote control and AAA batteries, RS232 cable, Wire Clamper (x 3) |
Miscellaneous |
|
On-Screen Display Languages |
English, French, German, Spanish, Polish, Turkish, Russian, Italian, Simplified Chinese, Traditional Chinese, Arabic, Japanese, Danish, Dutch, Finnish, Norwegian, Portuguese, Swedish |
Warranty |
3 year warranty |
Regulatory Approvals |
CE, CCC, RoHS, CB, EMF, FCC, Class A, EnergyStar 8.0, UL |
