| Design |
Colour: Black |
| Audio |
Sound output Power: 16 (2x8) W |
|
Speakers: 2.0 Down Firing |
|
Sound Features: AVL, Dynamic Bass, Incredible Surround, Dolby MS10 |
| Accessories |
Included: Edge Stand, 2 x AAA batteries, Power Cord, Warranty Leaflet, Legal and Safety brochure, Remote Control 22AV1903A/12 |
|
Optional: Easy RC 22AV1601B/12, Healthcare RC 22AV1604B/12, Setup RC 22AV9574A/12 |
| Tuner/Reception/Transmission |
Video Playback: NTSC, PAL, SECAM |
|
Analogue TV: PAL, SECAM |
|
Digital TV: DVB-T/T2/C, HEVC FHD (up to 1080p60) |
| Power |
EPREL registration number: 345104 |
|
Power Saving Features: Eco mode, Auto switch-off timer |
|
Energy Label Class: E |
|
Ambient temperature: 0 °C to 40 °C |
|
EU Energy Label power: 28 W |
|
Standby power consumption: <0.3 W |
|
Mains power: AC 220-240 V; 50-60 Hz |
| Dimensions |
Set Depth: 77 mm |
|
Product weight (+stand): 4.7 kg |
|
Set height (with stand): 455 mm |
|
Set width (with stand): 732 mm |
|
Set depth (with stand): 166 mm |
|
Set Height: 432 mm |
|
Set Width: 732 mm |
|
Wall-mount compatible: 100 x 100 mm M6 |
|
Product weight: 4.6 kg |
| Picture/Display |
Display: LED HD TV, D-LED |
|
Panel resolution: 1366 x 768p |
|
Diagonal screen size (metric): 80 cm |
|
Brightness: 250 cd/m² |
|
Viewing angle: 178º (H)/178º (V) |
|
Diagonal screen size (inch): 32 |
| Features |
Digital services: 8d EPG, Now and Next, MHEG, Teletext, Subtitles |
|
Local control: Joystick |
|
Ease of use: Picture Style, Sound Style, Picture Format, Independent volume control |
| Healthcare features |
Safety: Double isolation class II, Flame retardant |
|
Convenience: Headphone out, Independent main speaker mute, Headphone Detection |
|
Control: Multi-Remote Control, Healthcare RC compatible |
| Side Connectivity |
Headphone out: Mini-Jack |
|
Common Interface Slot: CI+ 1.3.2 |
|
USB1: USB 2.0 |
| Hospitality Features |
Timer: Sleep Timer, Wake Up Alarm, Wake Up On Channel, Wake Up Sounds |
|
Clock: Glow-in-the-Dark RC button, On-screen Clock |
|
CMND&Control: Remote Management over RF, TV Group management, Off-Line Settings Editor |
|
Languages: Guest language control |
|
Remote Control: Cable Strap Ready, Low-Battery Detection, RC Battery Door Lock |
|
Anti-Theft: Battery Anti-theft Protection, Kensington Lock |
|
Revenue generation: MyChoice |
|
Power control: Green/fast start-up |
|
Control: Block Automatic Channel Update, Switch On control |
| Cloning and Firmware update |
Instant Initial Cloning, Via USB/RF |
|
Hotel mode: Joystick Control Lock, Menu lock, Installation Menu Lock, Volume limitation |
|
Channels: Combined List, Off-Line Channel Editor |
|
Prison mode: high-security mode |
| Rear Connectivity |
VGA input: 15 pin D-sub |
|
Scart: CVBS, RGB |
|
Digital Audio out: Optical |
|
HDMI1: ARC, HDMI 1.4 |
|
DVI audio in: Mini-Jack |
|
Antenna: IEC-75 |
|
HDMI 2: HDMI 1.4 |
| Multimedia |
Video playback supported: H.264/MPEG4 AVC, MPEG1, MPEG2, MPEG4, WMV9/VC1, MP4, MPG, TS, WMV, HEVC |
|
Containers: AVI, MKV |
|
Subtitle formats supported: SRT, SMI, SSA SUB, TXT |
|
Music formats supported: MP3, AAC, WAV, WMA (v2 up to v9.2) |
|
Multimedia connections: USB |
|
Picture formats supported: BMP, JPG, PNG, GIF |
|
Supp. Video Resolution on USB: up to 1920x1080p@60Hz |
| Connectivity Enhancements |
HDMI: ARC (HDMI1), EasyLink (HDMI CEC): One touch play, System Standby, RC pass through, system audio control |
|
Scart: Power on scart |
