Picture/Display |
|
Diagonal Screen Size (inch) |
50 inch |
Diagonal Screen Size (metric) |
126 cm |
Display |
4K Ultra HD LED |
Panel Resolution |
3840 x 2160p |
Brightness |
350 cd/m² |
Viewing Angle |
178º (H) / 178º (V) |
Tuner/Reception/Transmission |
|
Digital TV |
DVB-T/T2/C, DVB-S/S2 |
IP Playback |
Unicast, Multicast |
OTT App Channels |
Android TV |
OS |
Android TV™ 11 (R) |
Pre-installed Apps |
YouTube, Google Play Movies, Google Play Games, YouTube Music, Google Play Store |
Memory Size (Flash) |
16 GB |
Hospitality Features |
|
Hotel Mode |
Yes |
Installation Menu Lock |
Yes |
Volume Limitation (incl. HP) |
Yes |
Switch-ON Settings Control |
Yes |
Prison Mode |
Yes |
Power Control |
Yes |
WoWLAN |
Yes |
WoLAN |
Yes |
Quick Start Mode |
Yes |
Auto Power OFF |
Yes |
Apps |
AppControl, Google Play Store, Your brand, Customisable Welcome App, CMND&Create, CMND&Control |
TV Group Management |
Yes |
Remote Management over IP |
Yes |
Local Updates via USB |
Yes |
Instant Initial Cloning |
Yes |
Interactive DRM |
Yes |
Revenue Generation |
MyChoice |
Remote Control |
Low-Battery Detection, RC Battery Door Lock |
Hygienic |
Yes |
CMND&Check-In |
Yes |
Guest Name |
Yes |
Guest Language |
Yes |
Sharing |
Secure Sharing, Network-managed Sharing, Chromecast Ultra built-in |
Convenience |
Sleep Timer, Google Assistant, Google Account Login, >40 Supported Menu Languages |
Healthcare Features |
|
Control |
Multi-Remote Control, Nurse Call System Compatible |
Convenience |
Headphone Out, Independent Main Speaker Mute |
Safety |
Double Isolation Class II, Flame Retardant |
Multimedia |
|
Video Playback Supported |
AVI, MKV, H.264/MPEG4 AVC, MPEG1, MPEG2, MPEG4, VP9, HEVC, AV1 |
Music Formats Supported |
MP3, WAV, AAC, WMA (v2 up to v9.2), WMA-PRO (v9 and v10) |
Subtitle Formats Supported |
SRT, SMI, SSA SUB, ASS, TXT |
Picture Formats Supported |
JPG, GIF, PNG, BMP |
Audio |
|
Sound Output Power |
20W (2x10) RMS |
Bathroom Speaker Out |
1.5 W Mono 8 ohm |
Speakers |
2.0 Down Firing |
Sound Features |
DTS Studio Sound, Dolby MS12D, AC-4, DTS-HD, Dolby Atmos Compatible |
Power |
|
Mains Power |
AC 220-240 V; 50-60 Hz |
Ambient Temperature |
0°C to 40°C |
Standby Power Consumption |
0.3W |
Power Saving Features |
Light Sensor, Eco Mode, Auto Switch-off Timer |
Accessories |
|
Included |
Edge Stand, Legal and Safety Brochure, Power Cord, 2x AA Batteries, Hygienic RC 22AV2304A |
Optional |
Setup RC 22AV9574A/12, Easy RC 22AV1601B/12, DOCSIS Cable Modem 22AV1970A |
Wireless Connectivity |
|
Wireless LAN |
Dual band 802.11 b/g/n, 802.11 ac, Wi-Fi-Direct 2 x 2 |
Bluetooth |
5.0, A2DP, SBC |
Connectivity Bottom |
|
HDMI 2 |
HDMI 2.0 |
Digital Audio Out |
Optical |
Ethernet (LAN) |
RJ-45 |
HDMI 3 |
HDMI 2.0 |
Bathroom Speaker Out |
Mini-Jack |
Antenna Input |
IEC-75, F-Type |
IR In/Out |
Mini-Jack |
Side Connectivity |
|
Common Interface Slot |
CI+ 1.4 |
HDMI1 |
HDMI 2.0 |
Headphone Out |
Mini-Jack |
USB1 |
USB 2.0 |
Connectivity Enhancements |
|
EasyLink (HDMI CEC) |
One Touch Play, System Standby, System Audio Control |
RC Pass Through |
HDMI ARC (HDMI1), HDCP 2.3 (all ports) |
Dimensions |
|
Set Width |
1112 mm |
Set Height |
647 mm |
Set Depth |
47/85 mm |
Product Weight |
11 kg |
Set Width (with Stand) |
1112 mm |
Set Height (with Stand) |
674 mm |
Set Depth (with Stand) |
247 mm |
Product Weight (+ Stand) |
11.1 kg |
Wall-Mount Compatible |
100 x 200 mm, M6 |
EU Energy Card |
|
EPREL Registration Numbers |
1827412 |
Energy Class for SDR |
F |
On Mode Power Demand for SDR |
61 kWh/1000 h |
Energy Class for HDR |
E |
On Mode Power Demand for HDR |
51 kWh/1000 h |
