Picture/Display |
|
Diagonal Screen Size (metric) |
138.7 cm |
Diagonal Screen Size (inch) |
54.6 inch |
Aspect Ratio |
16:9 |
Panel Resolution |
1920 x 1080p |
Pixel Pitch |
0.63 x 0.63 mm |
Optimum Resolution |
1920 x 1080 @ 60 Hz |
Brightness |
2500 cd/m² |
Display Colours |
1.07 Billion |
Contrast Ratio (Typical) |
4000:1 |
Dynamic Contrast Ratio |
500,000:1 |
Response Time (Typical) |
8 ms |
Viewing Angle (Horizontal) |
178° |
Viewing Angle (Vertical) |
178° |
Connectivity |
|
Audio Output |
3.5 mm jack |
Video Input |
Display Port 1.2 (x 1), DVI-I (x 1), HDMI 2.0 (x 2) |
Audio Input |
3.5 mm jack |
Other Connections |
OPS, USB 2.0 (x 2) |
Video Output |
DisplayPort 1.2 (x 1), HDMI 2.0 (x 1) |
External Control |
IR (in/out) 3.5 mm jack, RJ45, RS232C (in/out) 2.5 mm jack |
Convenience |
|
Placement |
Landscape (24/7), Portrait (24/7) |
Screen-Saving Functions |
Pixel Shift, Low Brightness |
Keyboard Control |
Hidden, Lockable |
Remote Control Signal |
Lockable |
Signal Loop Through |
DisplayPort, RS232, HDMI, IR Loop through |
Ease of Installation |
Carrying Handles, Smart Insert |
Energy-Saving Functions |
Smart Power |
Network Controllable |
RS232, RJ45 |
Sound |
|
Built-in Speakers |
2 x 10 W RMS |
Power |
|
Mains Power |
100 ~ 240 VAC, 50 ~ 60 Hz |
Consumption (Typical) |
245 W |
Consumption (Max) |
430 W |
Standby Power Consumption |
< 0.5 W |
Supported Display Resolution |
|
Computer Formats |
640 x 480, 720 x 400, 800 x 600, 1024 x 768, 1280 x 768, 1280 x 800, 1280 x 960, 1280 x 1024, 1360 x 768, 1366 x 768, 1600 x 1200, 1920 x 1080 |
Video Formats |
720p, 1080i, 1080p |
Dimensions |
|
Smart Insert Mount |
100 mm x 100 mm pitch, 6 x M4L6 |
Set Width |
1248.6 mm (49.16 inches) |
Set Height |
719.4 mm (28.32 inches) |
Set Depth |
85 mm (3.35 inches) |
Wall Mount |
400 x 400 mm, M6 |
Bezel Width |
17.5 mm (even bezel) |
Product Weight |
30.37 kg (66.95 lb) |
Smart Insert Height |
100 mm |
Operating Conditions |
|
Altitude |
0 ~ 3000 m |
Temperature Range (Operation) |
0 ~ 40 °C |
MTBF |
50,000 hours |
Temperature Range (Storage) |
-20 ~ 60 °C |
Humidity Range (Operation) |
20~80% RH (No condensation) |
Humidity Range (Storage) |
5~95% RH (No condensation) |
Multimedia Applications |
|
USB Playback Video |
AVI, MP4, MPEG, MPG, TS, VOB, MPEG4 |
USB Playback Picture |
BMP, JPEG, JPG, PNG |
Accessories |
|
Included Accessories |
AC Switch Cover, IR sensor cable (1.8 m), Philips logo, Quick start guide, Remote control and AAA batteries, USB Cover and screw, Wire Clamper (x 3), AC Power Cord, Edge Alignment Kit, Open-frame kit |
Miscellaneous |
|
On-Screen Display Languages |
Arabic, Dutch, English, French, German, Italian, Japanese, Polish, Portuguese, Russian, Spanish, Simplified Chinese, Turkish, Traditional Chinese |
Warranty |
3 year warranty |
Regulatory Approvals |
CE, FCC Class A, UL/cUL, CB |
